NO: Repair or replace the connector. Refer to GROUP 00E, Harness Connector Inspection P.00E-2. STEP 4. Check the wiring harness between A/C-ECU Q:Is the wiring harness between A/C-ECU connector C-109 (terminal 9 and 10) and A/C control panel connector C-119 (terminals 9 and 1) in good condition? YES: Go to Step 5. NO: Repair the wiring harness. STEP 5. Recheck for diagnostic trouble code. (1) Erase the DTC. (2) Turn the ignition switch to "ON" position. (3) Check if the DTC is set. Q:Is the check result satisfactory? YES: It can be assumed that this malfunction is intermittent. Refer to GROUP 00, How to Use NO: Replace the A/C control panel. Then go to Step 6. STEP 6. Recheck for diagnostic trouble code. (1) Erase the DTC. (2) Turn the ignition switch to "ON" position. (3) Check if the DTC is set. Q:Is the check result satisfactory? YES: It can be assumed that this malfunction is intermittent. Refer to GROUP 00, How to Use NO: Replace the A/C-ECU. AIR CONDITIONING 55A-19 MANUAL A/C DIAGNOSIS |
