MITSUBISHI MULTI-COMMUNICATION SYSTEM (MMCS) <VEHICLES WITH AUDIO AMPLIFIER>

TSB Revision

CIRCUIT DIAGRAMS

90-257

ETACS-ECU

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

INPUT SIGNAL

·AMBIENT AIR
 TEMPERATURE
 SENSOR
·COLUMN SWITCH
 (LIGHTING SWITCH)
·LIGHTING
 CONTROL SENSOR
 <VEHICLES WITH
 AUTOMATIC LIGHT>

CAN
TRANSCEIVER
CIRCUIT

A/C-
ECU

JOINT
CONNECTOR
(CAN1)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

MITSUBISHI MULTI-COMMUNICATION SYSTEM (MMCS) <VEHICLES WITH AUDIO AMPLIFIER>

TSB Revision

CIRCUIT DIAGRAMS

90-258

MITSUBISHI MULTI-COMMUNICATION SYSTEM (MMCS) <VEHICLES WITH AUDIO AMPLIFIER>



(CONTINUED)

AUDIO AMPLIFIER

MULTIVISION DISPLAY

REAR SEAT
ENTERTAINMENT
SYSTEM

·UNIVERSAL SERIAL
 BUS (USB) BOX
·HANDS-FREE
 INTERFACE SYSTEM

MITSUBISHI MULTI-COMMUNICATION SYSTEM (MMCS) <VEHICLES WITH AUDIO AMPLIFIER>

TSB Revision

CIRCUIT DIAGRAMS

90-259

SATELLITE
RADIO
TUNER

(FUSE     )

7

ETACS-ECU

POWER
SUPPLY

JOINT
CONNECTOR
(CAN1)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

MITSUBISHI MULTI-COMMUNICATION SYSTEM (MMCS) <VEHICLES WITH AUDIO AMPLIFIER>

TSB Revision

CIRCUIT DIAGRAMS

90-260

MITSUBISHI MULTI-COMMUNICATION SYSTEM (MMCS) <VEHICLES WITH AUDIO AMPLIFIER> (CON-
TINUED)

AUDIO AMPLIFIER

TWEETER

FRONT DOOR SPEAKER

(LH)

(LH)

(RH)

(RH)
