Mitsubishi Outlander GS45X. Manual - part 224





ENGINE COMPARTMENT <2.4L ENGINE>

TSB Revision

CONFIGURATION DIAGRAMS

80A-7

ACA01900

A-45

AB

A-06

A-07

A-08

A-09

A-11

A-10

A-12

A-13

A-37

A-39

A-40

A-14X
A-15X
A-16X
A-17X
A-18X

A-41

A-44

A-05

A-43

A-46

A-20X
A-21X
A-24X
A-26X
A-27X

A-28X
A-29X
A-31X
A-33X

15

12

4

A-66

A-65

A-29X (4)

Radiator fan relay

A-31X (5)

Fan control relay

A-33X (4)

MFI relay

A-37

(12-B)

Headlight assembly (LH)

A-39

(2-Y)

Front impact sensor (LH)

A-40

(4-B)

Spare connector (for trailer harness)

A-41

(2-B)

Fog light (LH)

A-43

(2-B)

Condenser fan motor

A-44

(2-B)

Ambient air temperature sensor

A-45

(1-B)

Horn (Low)

A-46

(2-B)

Front wiring harness and fog light
wiring harness combination

A-49

(1-B)

Horn (High)

A-50

(3-B)

A/C pressure sensor

A-51

(2-B)

Fog light (RH)

A-53

(2-Y)

Front impact sensor (RH)

A-54

(2-B)

Washer motor

A-56

(12-B)

Headlight assembly (RH)

A-58

(1-B)

Theft-alarm horn <Vehicles without
theft-alarm sensor>

A-59

(2-B)

Front wheel speed sensor (RH)

A-60

(2-B)

Side turn-signal light (RH) <Fender
panel type> or no connection <Door
mirror type>

A-61

(4-B)

Front wiring harness and theft-alarm
siren sub wiring harness combination
<Vehicles with theft-alarm sensor>

A-62

(4-B)

Theft-alarm siren <Vehicles with
theft-alarm sensor>

A-65

(4-GR)

Battery current sensor

A-66

(6-GR)

Ground (front: LH)

ENGINE COMPARTMENT <3.0L ENGINE>

TSB Revision

CONFIGURATION DIAGRAMS

80A-8

ENGINE COMPARTMENT <3.0L ENGINE>

M1801000308095

AC900421AD

Connector
symbol

A

A-01
A-02

A-03
A-61

Front wiring
harness

Grounding
cable

Fog light
wiring harness

A-49

A-50

A-53

A-51

A-54

A-56

A-64

A-57

A-58
A-62

A-59

A-60

1

Connector color
code
B: Black
BR: Brown
G: Green
GR: Gray
L: Blue
NONE: Milk white
O: Orange
R: Red
V: Violet
Y: Yellow

A-01

(26-B)

ABS-ECU

A-02

(47-B)

ASC-ECU

A-03

(4-B)

Front wiring harness and theft-alarm
horn sub wiring harness combination
<Vehicles without theft-alarm sensor>

A-05

(2-B)

Radiator fan motor

A-06

(2-B)

Hood latch switch

A-07

(4-GR)

Mass airflow sensor

A-08

(5-GR)

Windshield wiper motor

A-09

(2-B)

Brake fluid level switch

A-10

(2-B)

Side turn-signal light (LH) <Fender
panel type> or no connection <Door
mirror type>

A-11

(2-B)

Front wheel speed sensor (LH)

A-12

(24)

Front wiring harness and control
wiring harness combination

A-13

(20)

Front wiring harness and control
wiring harness combination

A-14X (4)

Fog light relay

A-15X (4)

Horn relay

A-16X (4)

A/C compressor relay

A-17X (4)

Theft-alarm horn relay <Vehicles
without theft-alarm sensor>

A-18X (4)

A/T control relay

A-20X (4)

Headlight relay (High)

A-21X (4)

Throttle actuator control motor relay

A-23X (4)

Daytime running light relay <Vehicles
with discharge type headlight>

A-24X (4)

Injector relay

A-27X (4)

Starter relay

A-28X (4)

Headlight relay (Low)

A-33X (4)

MFI relay

A-34X (4)

Radiator fan relay

ENGINE COMPARTMENT <3.0L ENGINE>

TSB Revision

CONFIGURATION DIAGRAMS

80A-9

ACA01901AB

A-06

A-07

A-08

A-09

A-10

A-11

A-12

A-13

A-63

A-37

A-39

A-40

A-14X A-18X A-24X
A-15X A-20X A-27X
A-16X A-21X A-28X
A-17X A-23X A-33X

A-34X
A-35X
A-36X

A-41

A-05

A-44

A-45

A-43

A-46

12

15

4

A-66

A-35X (4)

Condenser fan relay

A-36X (5)

Fan control relay

A-37

(12-B)

Headlight assembly (LH)

A-39

(2-Y)

Front impact sensor (LH)

A-40

(4-B)

Spare connector (for trailer harness)

A-41

(2-B)

Fog light (LH)

A-43

(2-B)

Condenser fan motor

A-44

(2-B)

Ambient air temperature sensor

A-45

(1-B)

Horn (Low)

A-46

(2-B)

Front wiring harness and fog light
wiring harness combination

A-49

(1-B)

Horn (High)

A-50

(3-B)

A/C pressure sensor

A-51

(2-B)

Fog light (RH)

A-53

(2-Y)

Front impact sensor (RH)

A-54

(2-B)

Washer motor

A-56

(12-B)

Headlight assembly (RH)

A-57

(3-GR)

No connection

A-58

(1-B)

Theft-alarm horn <Vehicles without
theft-alarm sensor>

A-59

(2-B)

Front wheel speed sensor (RH)

A-60

(2-B)

Side turn-signal light (RH) <Fender
panel type> or no connection <Door
mirror type>

A-61

(4-B)

Front wiring harness and theft-alarm
siren sub wiring harness combination
<Vehicles with theft-alarm sensor>

A-62

(4-B)

Theft-alarm siren <Vehicles with
theft-alarm sensor>

A-63

(6-B)

Headlight assembly (LH) <Vehicles
with discharge type headlight>

A-64

(6-B)

Headlight assembly (RH) <Vehicles
with discharge type headlight>

A-66

(6-GR)

Ground (front: LH)

ENGINE AND TRANSAXLE <2.4L ENGINE>

TSB Revision

CONFIGURATION DIAGRAMS

80A-10

ENGINE AND TRANSAXLE <2.4L ENGINE>

M1801000404517

AC900423

B-26

B-01

B-19

B-04

B-24

B-06

B-25

AD

B-16

B-23

B-17

Control wiring
harness

Connector
symbol

-01
thru
-26

B

Engine sub
wiring harness

Connector color
code
B: Black
BR: Brown
G: Green
GR: Gray
L: Blue
NONE: Milk white
O: Orange
R: Red
V: Violet
Y: Yellow

B-01

(3-B)

No.1 ignition coil

B-04

(3-B)

No.3 ignition coil

B-06

(2-B)

Knock sensor

B-07

(2-B)

Evaporative emission purge solenoid

B-08

(6-B)

Throttle body assembly

B-09

(2-B)

Engine coolant temperature sensor

B-10

(64-GR) Engine control module

B-11

(48-GR) Engine control module

B-12

(6-GR)

Exhaust gas recirculation valve

B-16

(1-L)

Engine oil pressure switch

B-17

(1-B)

A/C compressor assembly
