Mitsubishi Outlander (2013+). Manual - part 537





AC501053AC

T

T

2

T

: 0.08 ± 0.01 seconds

T

1

T

: 2.96 seconds

T

3

T

3

T

3

T

3

T

4

T

4

T

4

T

5

T

5

T

5

T

5

T

6

T

6

T

6

T

: 1.01 seconds

T

: 0.55 seconds

T

: 0.17 ± 0.01 seconds

T

: 0.11 ± 0.01 seconds

T

: 5.69 seconds

<Sound pattern 1>

<Sound pattern 2>

T

7

TROUBLESHOOTING <KOS-ECU>

KEYLESS OPERATION SYSTEM (KOS)

42B-9

WARNING AND WARNING INDICATOR
LIST <High contrast meter>

M1429612300634

When KOS failed or operated improperly, KOS-ECU
warns the driver of this by setting off the outer buzzer
and the keyless operation warning indicator on the
multi information display in the combination meter.

Item

Display content

State

Warning
operation

Warning cancellation
condition (when any
of the condition met)

Keyless
operation
key battery
low voltage
warning

AC809614

KEY
BATTERY
LOW

The keyless
operation key with
low battery voltage
is detected when
the engine switch
is pressed.

Warning
indicator display
for 30 seconds.

• Power supply mode

OFF is detected.

• 30 seconds have

passed after the
warning output
started.

Keyless
operation
key take out
warning

AC809615

KEY NOT
DETECTED

The keyless
operation key is
carried out of the
vehicle when the
power supply
mode is in other
than OFF, and the
door is closed.

• The warning

indicator
display for 5
minutes.

• Outer buzzer

sounds for
5.69 seconds
in pattern 2.

• Power supply mode

OFF is detected.

• KOS-ECU has

detected a keyless
operation key
inside the vehicle.

• 5 minutes have

passed when the
power supply mode
is in ACC.

Door lock
does not
operate
(keyless
operation
key is
located
inside the
vehicle).

AC809615

KEY STILL
IN VEHICLE

The lock/unlock
switch of the front
door outside
handle is pressed
when the keyless
operation key is
still located inside
the car.

• Warning

indicator
display for 5
seconds.

• Outer buzzer

sounds for
2.96 seconds
in pattern 1.

• Lock/unlock switch

of the front door
outside handle is
pressed again.

• 5 seconds have

passed after the
warning output
started.

TROUBLESHOOTING <KOS-ECU>

KEYLESS OPERATION SYSTEM (KOS)

42B-10

Door lock
does not
operate
(door open).

AC809615

CHECK
DOORS

The lock/unlock
switch on the front
door outside
handle is pressed
when the door is
ajar.

• Warning

indicator
display for 5
seconds.

• Outer buzzer

sounds for
2.96 seconds
in pattern 1.

• All doors are

closed.

• 5 seconds have

passed after the
warning output
started.

System
error

AC809615

KEYLESS
OPERATIO
N SYSTEM
SERVICE
REQUIRED

Engine switch is
pressed when an
error has been
detected in
EEPROM of
KOS-ECU.

The warning
indicator display
for 5 minutes.

5 minutes have
passed after the
engine switch is
pressed, also the
power supply mode is
OFF.

Engine switch is
pressed when a
transmission
antenna has an
open circuit or
short to power
supply.

Open circuit or
short to earth is
detected in the key
slot.

An error is
detected, and the
power supply
mode is other than
OFF.

No keyless
operation
key detected
inside the
car

AC904250

KEY NOT
DETECTED
INSERT
KEY INTO
KEY SLOT

No keyless
operation key is
detected inside the
car when the
engine switch is
pressed.

The warning
indicator display
for 5 seconds.

• Power supply mode

OFF is detected.

• 5 seconds have

passed after the
warning output
started.

Key
reminder

AC904251

REMOVE
KEY FROM
KEY SLOT

With the driver's
door kept open,
the keyless
operation key is
not removed from
the key slot.

• The warning

indicator
display for 1
minute.

• Outer buzzer

sounds for
2.96 seconds
in pattern 1.

• Key is removed

from the key slot.

• 1 minutes have

passed after the
warning output
started.

Item

Display content

State

Warning
operation

Warning cancellation
condition (when any
of the condition met)

TROUBLESHOOTING <KOS-ECU>

KEYLESS OPERATION SYSTEM (KOS)

42B-11

DIAGNOSIS CODE CHART

M1429600200953

Engine
switch
reminder

AC904252

The lock/unlock
switch on the front
door outside
handle (driver's
side, front
passenger's side)
or the tailgate lock
release handle
(tailgate open
switch, tailgate
lock switch) are
pressed when the
power supply
mode is other than
OFF.

• Warning

indicator
display for 5
seconds.

• Outer buzzer

sounds for
2.96 seconds
in pattern 1.

5 minutes have
passed after the
engine switch is
pressed, also the
power supply mode is
OFF.

AC501053AE

T

T

2

T

: 0.08 ± 0.01 second

T

1

T

: 2.96 seconds

T

3

T

3

T

3

T

3

T

4

T

4

T

4

T

5

T

5

T

5

T

5

T

6

T

6

T

6

T

: 1.01 seconds

T

: 0.55 second

T

: 0.17 ± 0.01 second

T

: 0.11 ± 0.01 second

T

: 5.69 seconds

<Sound pattern 1>

<Sound pattern 2>

T

7

Item

Display content

State

Warning
operation

Warning cancellation
condition (when any
of the condition met)

Diagnosis code No.

Diagnostic item

Reference
page

B1761

Chassis No.not programmed

P.42B-13

B1770

Implausible coding data

P.42B-13

B1A08

Keyless/KOS key1 performance

P.42B-14

B1A09

Keyless/KOS key2 performance

B1A0A

Keyless/KOS key3 performance

B1A0B

Keyless/KOS key4 performance

B1A10

Keyless/KOS key 1 low battery

P.42B-15

B1A11

Keyless/KOS key 2 low battery

B1A12

Keyless/KOS key 3 low battery

B1A13

Keyless/KOS key 4 low battery

TROUBLESHOOTING <KOS-ECU>

KEYLESS OPERATION SYSTEM (KOS)

42B-12

NOTE:

.

*1

: OSS = One-touch start system

*2

: LF= Low frequency

*3

: ESL = Electronic steering lock

B1A24

Key ID not registered

P.42B-15

B1A25

Key ID unmatched

P.42B-16

B2101

IG SW start POS circuit low

P.42B-17

B2102

IG SW start POS circuit high

B2204

Coding data mismatch

P.42B-18

B2206

Chassis No. mismatch

P.42B-19

B2352

Antenna fail

P.42B-19

B2400

KOS key registration fail

P.42B-20

B2401

Keyless/KOS key ID not registered

P.42B-21

B240A

DR side antenna(outdoor) open

P.42B-21

B240B

PS side antenna(outdoor) open

P.42B-22

B240C

Tail gate antenna(outdoor) open

P.42B-22

B240D

Front antenna(indoor) open

P.42B-23

B240E

RR antenna(indoor) open

P.42B-24

B2416

ECU internal error

P.42B-25

B2417

OSS authentification error

*1

P.42B-25

B2418

OSS authentification timeout

*1

P.42B-25

B2419

LF antenna voltage short*

2

P.42B-26

B241A

ESL power control circuit earth

*3

P.42B-27

B241B

ESL power control circuit open

*3

U0141

ETACS CAN timeout

P.42B-27

U0155

Meter CAN timeout

P.42B-28

U0164

A/C-ECUCAN timeout

P.42B-29

U0230

Electric tailgate control unit CAN timeout

P.42B-30

U0245

AND CAN timeout

P.42B-30

U1000

OSS CAN timeout

*1

P.42B-31

U1190

No receive fault detect signal

P.42B-31

U1195

Coding not completed

P.42B-32

Diagnosis code No.

Diagnostic item

Reference
page
