Mitsubishi Outlander (2003+). Manual - part 319

KEYLESS ENTRY SYSTEM

BODY

42-51

ENABLING/DISABLING THE
ANSWERBACK FUNCTION

M1428003200322

If the keyless entry system locks or unlocks the
doors, the room lamp flashes or illuminates, the
hazard warning lamp flashes (hazard answerback
function). The hazard answerback function can be
enabled or disabled according to the following
procedure:

ENABLING/DISABLING THE HAZARD
ANSWERBACK FUNCTION

The hazard answerback function can be enabled or
disabled by one of the two following procedures.
<When using the transmitter after diagnosis
connector (1) is earthed>
1. Enter the hazard answerback customize mode by

performing one of the following steps. If the
ETACS-ECU enters the customize mode, its
buzzer will sound once.
(1) Turn the ignition switch to “LOCK”(OFF)

position.

(2) Turn off the hazard warning lamp switch.

CAUTION

Before connecting or disconnecting the earth,
turn the ignition switch to the "LOCK" (OFF)
position.

(3) Connect the diagnosis connector to the

special tool diagnosis code check harness
MB991529.

(4) Close the driver's side door.
(5) Keep the windshield washer switch on for at

least ten seconds. Then the ETACS-ECU
buzzer will sound once.

2. If the transmitter “LOCK” button is pushed

consecutively twice (within two seconds), the
ETACS-ECU buzzer will sound, indicating that the
hazard answerback function can be enabled or
disabled when the doors are locked.

•

Enable the hazard answerback function
when the doors are locked: The
ETACS-ECU buzzer will sound once.

•

Disable the hazard answerback function
when the doors are locked: The
ETACS-ECU buzzer will sound twice.

3. If the transmitter “UNLOCK” button is pushed

consecutively twice (within two seconds), the
ETACS-ECU buzzer will sound, indicating that the
hazard answerback function can be enabled or
disabled when the doors are unlocked.

•

Enable the hazard answerback function
when the doors are unlocked: The
ETACS-ECU buzzer will sound once.

•

Disable the hazard answerback function
when the doors are unlocked: The
ETACS-ECU buzzer will sound twice.

4. Exit the hazard answerback customize mode by

observing one of the following steps.
(1) Disconnect diagnosis connector terminal (1)

form the earth.

(2) Turn the ignition switch to position other then

“LOCK”(OFF), or remove the ignition key.

(3) Open the driver's side door,
(4) Any other warning buzzer output occurs.

NOTE: If any operation is not done for at least three
minutes after the ETACS-ECU has entered the
customize mode, the hazard answerback customize
mode will be canceled automatically.

AC107528 AC

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16

MB991529

Diagnosis

connector

KEYLESS ENTRY SYSTEM

BODY

42-52

<When the transmitter is used after connecting
MUT-II to the diagnosis connector>
1. Enter the hazard answerback customize mode by

performing one of the following steps. If the
ETACS-ECU enters the customize mode, its
buzzer will sound once.
(1) Turn the ignition switch to “LOCK”(OFF)

position.

(2) Turn off the hazard warning lamp switch.

CAUTION

Before connecting or disconnecting the MUT-II,
turn the ignition switch to the "LOCK" (OFF)
position.

(3) Connect the MUT-II to the diagnosis

connector.

(4) Close the driver's side door.
(5) Keep the windshield washer switch on for at

least ten seconds. Then the ETACS-ECU
buzzer will sound once.

2. If the transmitter “LOCK” button is pushed

consecutively twice (within two seconds), the
ETACS-ECU buzzer will sound, indicating that the
hazard answerback function can be enabled or
disabled when the doors are locked.

•

Enable the hazard answerback function
when the doors are locked: The
ETACS-ECU buzzer will sound once.

•

Disable the hazard answerback function
when the doors are locked: The
ETACS-ECU buzzer will sound twice.

3. If the transmitter “UNLOCK” button is pushed

consecutively twice (within two seconds), the
ETACS-ECU buzzer will sound, indicating that the
hazard answerback function can be enabled or
disabled when the doors are unlocked.

•

Enable the hazard answerback function
when the doors are unlocked: The
ETACS-ECU buzzer will sound once.

•

Disable the hazard answerback function
when the doors are unlocked: The
ETACS-ECU buzzer will sound twice.

4. Exit the hazard answerback customize mode by

observing one of the following steps.
(1) Disconnect MUT-II from the diagnosis

connector.

(2) Turn the ignition switch to position other then

“LOCK”(OFF), or remove the ignition key.

(3) Open the driver's side door,
(4) Any other warning buzzer output occurs.

NOTE: If any operation is not done for at least three
minutes after the ETACS-ECU has entered the
customize mode, the hazard answerback customize
mode will be canceled automatically.

AC107200AC

MB991502

16 Pin

KEYLESS ENTRY SYSTEM

BODY

42-53

<When the transmitter is used after connecting
special tool V. C. I. MB991824 to the diagnosis
connector>
1. Enter the hazard answerback customize mode by

performing one of the following steps. If the
ETACS-ECU enters the customize mode, its
buzzer will sound once.
(1) Turn the ignition switch to “LOCK”(OFF)

position.

(2) Turn off the hazard warning lamp switch.

CAUTION

Before connecting or disconnecting the V. C. I.,
turn the ignition switch to the "LOCK" (OFF)
position.

(3) Connect the V. C. I. to the diagnosis

connector.

(4) Turn the V.C.I. power switch to the "ON"

position.

(5) Close the driver's side door.
(6) Keep the windshield washer switch on for at

least ten seconds. Then the ETACS-ECU
buzzer will sound once.

2. If the transmitter “LOCK” button is pushed

consecutively twice (within two seconds), the
ETACS-ECU buzzer will sound, indicating that the
hazard answerback function can be enabled or
disabled when the doors are locked.

•

Enable the hazard answerback function
when the doors are locked: The
ETACS-ECU buzzer will sound once.

•

Disable the hazard answerback function
when the doors are locked: The
ETACS-ECU buzzer will sound twice.

3. If the transmitter “UNLOCK” button is pushed

consecutively twice (within two seconds), the
ETACS-ECU buzzer will sound, indicating that the
hazard answerback function can be enabled or
disabled when the doors are unlocked.

•

Enable the hazard answerback function
when the doors are unlocked: The
ETACS-ECU buzzer will sound once.

•

Disable the hazard answerback function
when the doors are unlocked: The
ETACS-ECU buzzer will sound twice.

4. Exit the hazard answerback customize mode by

observing one of the following steps.
(1) Disconnect V. C. I. from the diagnosis

connector.

(2) Turn the ignition switch to position other then

“LOCK”(OFF), or remove the ignition key.

(3) Open the driver's side door.
(4) Any other warning buzzer output occurs.

NOTE: If any operation is not done for at least three
minutes after the ETACS-ECU has entered the
customize mode, the hazard answerback customize
mode will be canceled automatically.

AC305321

AC

MB991911

MB991824

16-Pin

KEYLESS ENTRY SYSTEM

BODY

42-54

HOW TO REGISTER SECRET CODE

M1428001000418

Each individual secret code is registered inside the
transmitter, and so it is necessary to resister these
codes with the EEPROM inside the receiver in the
following cases.

•

When the transmitter or ETACS-ECU is replaced

•

If more transmitters are to be used

•

If it appears that a problem is occurring because
of faulty registration of a code.

A maximum of four different codes can be stored in
the EEPROM memory (four different transmitters can
be used). When the code for the first transmitter is
registered, the previously registered codes for all
transmitters are cleared. Therefore, if you are using
four transmitters or are adding more transmitters, the
codes for all transmitters must be registered at the
same time.

When special tool diagnosis code check
harness MB991529 is used

1. Check that the doors lock normally when the key

is used.

2. Insert the ignition key.

CAUTION

Before connecting or disconnecting the earth,
turn the ignition switch to the "LOCK" (OFF)
position.

3. Connect the diagnosis connector to the special

tool diagnosis code check harness MB991529.
NOTE: This will connect terminal (1) of the
diagnosis connector to earth, and the system will
be in secret code registration standby mode.

4. Press the hazard warning lamp switch six times

within 10 seconds.
NOTE: Once the process is completed six times,
then it will operate with all doors and tailgate lock
and unlock operations once and then go to the
save mode.
NOTE: The hazard warning lamp switch is turned
on and off alternately whenever it is pushed.

5. Press the transmitter switch, and then press it two

times within 10 seconds of the first press. This will
register the code.

6.  Once the program is saved, it will operate once

with the all doors and tailgate lock and unlock
operations.

7. If you are using two or more transmitters or have

added a second transmitter, the same registration
procedure should be carried out within one minute
after registering the code for the first transmitter.

8. Registration mode will be canceled under the

following conditions:

•

When the secret code for four transmitters has
been registered;

•

When one minute has passed after registration
mode started;

•

When the diagnosis connector is disconnected
from earth

•

When the key is removed from the key cylinder;

9. After the registration is completed, remove the

ignition key and close all the doors, and then
check that the keyless entry system operates
normally.

AC107528 AC

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16

MB991529

Diagnosis

connector

ACX00571

Ground connected

Within 10 seconds

Hazard
warning
switch

ON

OFF

1

2

3

4

5

6

AG
