Mitsubishi Outlander (2003+). Manual - part 102





TROUBLESHOOTING

MULTIPORT FUEL INJECTION (MFI)

13A-271

Inspection Procedure 29: A/C Pressure Sensor System

OPERATION

œ

A power voltage of 5 V is applied to the A/C pres-
sure sensor power terminal (terminal No. 3) from
the engine-ECU (terminal No. 81) and is earthed
to the engine-ECU (terminal No. 92) from the A/C
pressure sensor (terminal No. 1).

œ

The sensor signal is inputted to the engine-ECU
(terminal No. 42) from the A/C pressure sensor
output terminal (terminal No. 2).

FUNCTION

œ

The A/C pressure sensor detects the A/C refrig-
erant pressure and inputs the pressure signal to
the engine-ECU. The engine-ECU uses the sig-
nal for ON/OFF control of the magnet clutch of
the A/C compressor.

PROBABLE CAUSE

œ

Failed A/C pressure sensor

œ

Open/short circuit in A/C pressure sensor circuit
or loose connector contact

œ

Failed engine-ECU

AK300339

5 V

3

2

1

34

33

32

36

35

37

42

45

31

39

38

46

40 41

43 44

82

78

81

80

89 90 9192

79

87

71

74

73

72

76

75

77

85

88

83 84

86

AB

Engine-ECU

81

92

42

      A-02
(MU802509)

C-116

A/C-ECU

3

G-Y

G-R

G-R

G-R

BR

BR

BR

G-Y

17

A-14

1

2

A/C Pressure sensor circuit

A/C Pressure sensor

5

4

17

21

C-105

C-104

C-135

C-137

Wire colour code
B: Black  LG: Light green  G: Green  L: Blue  W: White  Y: Yellow  SB: Sky blue  BR: Brown  O: Orange  GR: Gray
R: Red  P: Pink  V:Violet

TROUBLESHOOTING

MULTIPORT FUEL INJECTION (MFI)

13A-272

DIAGNOSIS PROCEDURE

STEP 1. MUT-II Data List

œ

Refer to Data list reference table

3

13A



.

a. Item 3A: A/C pressure sensor

Q: Is the check result normal?

YES :

Intermittent malfunction (Refer to GROUP

00

-

 How to Use

Troubleshooting/Inspection Service Points

3

00



).

NO :

Go to Step 2 .

STEP 2. Connector check: A-02 A/C pressure
sensor connector

Q: Is the check result normal?

YES :

Go to Step 3 .

NO :

Repair.

STEP 3. Measure voltage at A-02 A/C pressure
sensor connector.

œ

Disconnect connector, and measure at harness
side.

œ

Ignition switch: ON

œ

Voltage between terminal No. 3 and earth.

OK: 4.9

-

 5.1 V

Q: Is the check result normal?

YES :

Go to Step 9 .

NO :

Go to Step 4 .

STEP 4. Measure voltage at C-137 engine-ECU
connector.

œ

Measure engine-ECU terminal voltage.

œ

Ignition switch: ON

œ

Voltage between terminal No. 81 and earth.

OK: 4.9

-

 5.1 V

Q: Is the check result normal?

YES :

Go to Step 6 .

NO :

Go to Step 5 .

AK300340

1

2

3

Harness side
connector

A-02 (B)

AB

Connector: A-02

AK300340

1

2

3

Harness side
connector

A-02 (B)

AB

Connector: A-02

AK300340

1

2

3

Harness side
connector

A-02 (B)

AB

Connector: A-02

AK300254

82

78

8180

89

90

91

92

79

87

71

74 73 72

76 75

77

85

88

83

84

86

AB

CONNECTOR: C-137

C-137

Harness side connector

TROUBLESHOOTING

MULTIPORT FUEL INJECTION (MFI)

13A-273

STEP 5. Connector check: C-137 engine-ECU
connector

Q: Is the check result normal?

YES :

Check intermediate connector A-14, and

repair if necessary. If intermediate
connector is normal, check and repair
harness between A-02 (terminal No. 3) A/C
pressure sensor connector and C-137
(terminal No. 81) engine-ECU connector.

œ

Check power line for open circuit.

NO :

Repair.

STEP 6. Connector check: C-137 engine-ECU
connector

Q: Is the check result normal?

YES :

Go to Step 7 .

NO :

Repair.

AK300254

82

78

8180

89

90

91

92

79

87

71

74 73 72

76 75

77

85

88

83

84

86

AB

CONNECTOR: C-137

C-137

Harness side connector

AK300340

1

2

3

Harness side
connector

A-02 (B)

AB

Connector: A-02

AK300254

82

78

8180

89

90

91

92

79

87

71

74 73 72

76 75

77

85

88

83

84

86

AB

CONNECTOR: C-137

C-137

Harness side connector

TROUBLESHOOTING

MULTIPORT FUEL INJECTION (MFI)

13A-274

STEP 7. Check harness between A-02 (terminal
No. 3) A/C pressure sensor connector and C-137
(terminal No. 81) engine-ECU connector.

NOTE: Before checking harness, check intermediate
connector A-14, and repair if necessary.

œ

Check power line for short circuit.

Q: Is the check result normal?

YES :

Go to Step 8 .

NO :

Repair.

STEP 8. MUT-II Data List

œ

Refer to Data list reference table

3

13A



.

a. Item 3A: A/C pressure sensor

Q: Is the check result normal?

YES :

Intermittent malfunction (Refer to GROUP

00

-

 How to Use

Troubleshooting/Inspection Service Points

3

00



).

NO :

Replace engine-ECU.

STEP 9. Measure resistance at A-02 A/C pressure
sensor connector.

œ

Disconnect connector, and measure at harness
side.

œ

Resistance between terminal No. 1 and earth

OK: 2

W

 or less

Q: Is the check result normal?

YES :

Go to Step 12 .

NO :

Go to Step 10 .

STEP 10. Connector check: C-137 engine-ECU
connector

Q: Is the check result normal?

YES :

Go to Step 11 .

NO :

Repair.

AK300340

1

2

3

Harness side
connector

A-02 (B)

AB

Connector: A-02

AK300254

82

78

8180

89

90

91

92

79

87

71

74 73 72

76 75

77

85

88

83

84

86

AB

CONNECTOR: C-137

C-137

Harness side connector

AK300340

1

2

3

Harness side
connector

A-02 (B)

AB

Connector: A-02

AK300254

82

78

8180

89

90

91

92

79

87

71

74 73 72

76 75

77

85

88

83

84

86

AB

CONNECTOR: C-137

C-137

Harness side connector
