Mitsubishi Montero Sport (2004+). Manual - part 376





SPECIAL TOOLS

TSB Revision

AUTOMATIC TRANSMISSION OVERHAUL

23B-7

SPECIAL TOOLS

M1233000600129

TRANSMISSION

TOOL

TOOL NUMBER AND
NAME

SUPERSESSION

APPLICATION

MB990929
Installer adapter

MB990929

Installation of oil seal

MB990938
Handle

MB990938-01

Use with installer adapter

MD998727
Oil pan remover

Removal of oil pan

MD998333
Oil pump remover

MD998333-01

Removal of oil pump

MB991603
Bearing installer stopper

Measurement of output
shaft and center support
end plays

MD998304
Oil seal installer

MD998304-01

Measurement of output
shaft end play

MB991632
Clearance dummy plate

Measurement of brake
reaction plate, second
brake and low/reverse
brake end plays

B990938

D998727

SPECIAL TOOLS

TSB Revision

AUTOMATIC TRANSMISSION OVERHAUL

23B-8

MD998913
Dial gauge extension

MD998913-01

Measurement of brake
reaction plate, second
brake and low/reverse
brake end plays

MD998412
Guide

MD998412

Installation of oil pump

MD998316
Dial gauge support

MIT209038

Measurement of input
shaft end play

MD998924
Spring compressor
retainer

Use with spring
compressor

MD999590
Spring compressor

Removal and installation
of reverse and overdrive
clutch spring retainer
snap ring

MB991629
Spring compressor

Measurement of
overdrive clutch and
underdrive clutch end
plays

TOOL

TOOL NUMBER AND
NAME

SUPERSESSION

APPLICATION

SPECIAL TOOLS

TSB Revision

AUTOMATIC TRANSMISSION OVERHAUL

23B-9

TRANSFER

MB991789
Spring compressor

Adjustment reverse clutch
end plays

MB991630
Spring compressor

Removal and installation
of center support snap
ring

MD998907
Spring compressor

MD998907-01

Removal and installation
of underdrive clutch
spring retainer snap ring

TOOL

TOOL NUMBER AND
NAME

SUPERSESSION

APPLICATION

TOOL

TOOL NUMBER AND
NAME

SUPERSESSION

APPLICATION

MB990929
Installer adapter

MB990929

Installation of oil seal

MB990938
Handle

MB990938-01

Use with installer adapter

MB990936
Installer adapter

Installation of oil seal

MD998801
Bearing remover

MD998348-01

Removal and installation
of bearing

B990938

SPECIAL TOOLS

TSB Revision

AUTOMATIC TRANSMISSION OVERHAUL

23B-10

MD998812
Installer cap

General service tool

Use with installer and
installer adapter

MD998826
Installer adapter (52)

General service tool

Installation of transfer
input gear bearing

MD998818
Installer adapter (38)

MD998818

Installation of
countershaft gear
bearing, front output shaft
bearing

MD998368
Bearing Installer

General service tool

Installation of
countershaft gear bearing

MD998814
Installer-200

MIT304180

Use with installer cap and
installer adapter

MD998823
Installer adapter (48)

General service tool

Installation of rear output
shaft bearing

MD998192
Counter gear bearing
puller

MD998192

Installation of transfer
drive shaft bearing

TOOL

TOOL NUMBER AND
NAME

SUPERSESSION

APPLICATION
