TRANSFER DIAGNOSIS <ACTIVE TRAC AWD II>

TSB Revision

AUTOMATIC TRANSMISSION

23A-475

STEP 5. Check harness for open circuit or short circuit to
ground between free-wheel engage solenoid valve
connectors A-38, A-39 terminal 1 and junction block
connector D-208 terminal 2.
Q: Is the harness wire in good condition?

YES : Go to Step 10.
NO :  Repair or replace the harness wire.

AC204184

CONNECTORS : A-38, A-39

A-38 (B)

A-39 (BR)

AD

A-38

2

1

A-39

2

1

AC204173

CONNECTOR : D-208

BA

5 6

2

4

3

1

JUNCTION BLOCK
(FRONT VIEW)

TRANSFER DIAGNOSIS <ACTIVE TRAC AWD II>

TSB Revision

AUTOMATIC TRANSMISSION

23A-476

STEP 6. Measure the solenoid valve output voltage at the
transfer-ECU connector E-104 by backprobing.
(1) Do not disconnect connector E-104.
(2) Turn the ignition switch to the "ON" position.
(3) Transmission range should be "N" range.

(4) Measure the voltage between terminal 41 and ground by

backprobing.

• When the transfer shift lever position is other than 2H,

voltage should measure battery positive voltage.

• When the transfer shift lever position is 2H, voltage

should measure less than 1.0 volt.

(5) Turn the ignition switch to the "LOCK" (OFF) position.
Q: Is the measured voltage normal?

YES : Go to Step 9.
NO :  Go to Step 7.

AC204176

CONNECTOR : E-104

BA

51

40

3839

50

41

52

48

37

46

35

47

36

45

34

43

32

44

33

49

42

31

AC204918 BW

E-104 HARNESS CONNECTOR :
HARNESS SIDE

51

40

3839

50

41

52

48

37

46

35

47

36

45

34

43

32

44

33

49

42

31

TRANSFER DIAGNOSIS <ACTIVE TRAC AWD II>

TSB Revision

AUTOMATIC TRANSMISSION

23A-477

STEP 7. Check joint connector A-17, free-wheel engage
solenoid valve connectors A-38, A-39, intermediate
connectors A-03, E-114 and transfer-ECU connector E-104
for loose, corroded or damaged terminals, or terminals
pushed back in the connector.

AC204185

CONNECTORS : A-03, A-17

A-03 (B)

A-03

A-17 (GR)

A-17

AI

6

12

5

3 4

2

1

9 10

8

7

11

1213

4 5

14

10

3

8 9

2

7

1

6

11

AC204184

CONNECTORS : A-38, A-39

A-38 (B)

A-39 (BR)

AD

A-38

2

1

A-39

2

1

TRANSFER DIAGNOSIS <ACTIVE TRAC AWD II>

TSB Revision

AUTOMATIC TRANSMISSION

23A-478

Q: Are the connectors and terminals in good condition?

YES : Go to Step 8.
NO :  Repair or replace the damaged components. Refer to

GROUP 00E, Harness Connector Inspection

P.00E-2

.

AC204194

CONNECTORS : E-104, E-114

E-104

E-104

E-114

E-114

AU

51

40

3839

50

41

52

48

37

46

35

47

36

45

34

43

32

44

33

49

42

31

38

28

16

33

22

10

31

19

7

1

18

30

29

17

5

6

21

20

32

8

2

9

25

13

3

24

23

3435

1112

27

26

3637

14

4

15
