PROPELLER SHAFT TSB Revision PROPELLER SHAFT 25-7 <<B>> REAR PROPELLER SHAFT ASSEMBLY REMOVAL CAUTION When working with the CFRP propeller shaft assembly, the rubber sheet. 2. Make mating marks on the differential companion flange and the outer race of ball joint assembly. CAUTION • Do not bend the joint portion when removing the pro- peller shaft because this will damage the joint boot. • Do not drop the air breather at the end portion of pro- peller shaft differential side into the propeller shaft ball • Do not drop, shock, or scratch the propeller shaft. it with new one. If the dropped rear propeller shaft is 3. Remove the rear propeller shaft assembly after placing a rag around the joint boot portion. 4. Cover the transfer case opening to prevent foreign material from entering. INSTALLATION SERVICE POINTS . >>A<< REAR PROPELLER SHAFT ASSEMBLY INSTALLA- the rubber sheet. ACX00638 AB RUBBER SHEET OR ACX00919AB AIR BREATHER ACX00641AB PROPELLER JOINT BOOT RAG JOINT ACX00638 AB RUBBER SHEET OR |
