TRANSMISSION
TSB Revision
AUTOMATIC TRANSMISSION OVERHAUL
23B-39
(13) Remove the parts installed in steps 24 (1) to (12).
CAUTION
Make sure thrust bearing number 7 is mounted in the cor-
rect direction.
25.Apply Vaseline or petroleum jelly on the thrust bearing
number 7, and then install on the rear side of the
low/reverse annulus gear.
CAUTION
Make sure that thrust bearing number 7 attached to the
rear side of the low/reverse annulus gear does not fall off.
26.Install the low/reverse annulus gear.
2.1 or more
− less than 2.3 (0.083 or more − less than 0.091) 2.4 (0.094)
B
MD759428
2.3 or more
− less than 2.5 (0.091 or more − less than 0.098) 2.6 (0.102)
A
MD759429
2.5 or more
− less than 2.7 (0.098 or more − less than 0.106) 2.8 (0.110)
0
MD759430
2.7 or more
− less than 2.9 (0.106 or more − less than 0.114) 3.0 (0.118)
1
MD759431
MOVING AMOUNT mm (in)
PRESSURE PLATE
THICKNESS
mm (in)
ID SYMBOL ID SYMBOL
AKX00087
THRUST
BEARING NO.7
AB
AKX00088
THRUST
BEARING NO.7
AB
