MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) 13A-71 DIAGNOSIS Required Special Tools: • MB991958: Scan Tool (MUT-III Sub Assembly) • MB991824: V.C.I. • MB991827: USB Cable • MB991911: Main Harness B STEP 1. Using scan tool MB991958, check data list item 95: CAUTION To prevent damage to scan tool MB991958, always turn the 95, Manifold absolute Pressure Sensor. • When altitude is 0 m (0 foot), 101 kPa (29.8 in.Hg). • When altitude is 600 m (1,969 feet), 95 kPa (28.1 in.Hg). • When altitude is 1,200 m (3,937 feet), 88 kPa (26.0 in.Hg). • When altitude is 1,800 m (5,906 feet), 81 kPa (23.9 in.Hg). (4) Start the engine. • When the engine is idling, 16 − 36 kPa (4.7 − 10.6 in.Hg). • When the engine is suddenly revved, manifold absolute pressure increases. (5) Turn the ignition switch to the "LOCK" (OFF) position. YES : It can be assumed that this malfunction is intermittent. Refer to GROUP 00, How to Use NO : Go to Step 2. AK302970 AB MB991911 MB991824 MB991827 |
