M-ASTC DIAGNOSIS TSB Revision MITSUBISHI ACTIVE SKID AND TRACTION CONTROL SYSTEM 35C-75 STEP 5. Measure the voltage in the CAN_L line. Check at CAUTION Before checking CAN bus lines and their interconnected CAUTION When measuring resistance value or voltage in CAN bus wheel sensor connector D-225, and measure the voltage at (2) Turn the ignition switch to the "ON" position. (3) Measure the voltage between intermediate connector E-122 terminal 20 and body ground. • The voltage should measure one volt or less. Q: Does the voltage measure one volt or less? YES : Go to Step 10. AC204172 CONNECTOR: D-225 HARNESS SIDE AD 3 2 1 4 5 AC204176 CONNECTOR: E-122 E-122(L) MALE SIDE E-122(L) AF 1 12 2 13 3 14 4 15 5 16 6 17 7 18 8 19 9 20 10 21 11 22 AC204580 MALE CONNECTOR: E-122 AC TEST 1 12 2 13 3 14 4 15 5 16 6 17 7 18 8 19 9 20 10 21 11 22 |
