TRANSFER
TSB Revision
AUTOMATIC TRANSMISSION OVERHAUL
23B-107
>>B<< OIL SEAL INSTALLATION
1. Use special tools MB990929 and MB990938 to install the oil
seal.
2. Apply MITSUBISHI genuine grease Part number 0101011 or
equivalent to the lip of the oil seal.
.
>>C<< REAR BEARING RETAINER INSTALLATION
Apply MITSUBISHI genuine sealant part number MD997740 or
equivalent to the threads.
NOTE: The new bolt is precoated with sealant, so sealant does
not need to be applied.
.
>>D<< SNAP RING INSTALLATION
Select and install the snap ring which adjusts the H-L clutch
hub end play to the standard value.
Standard value: 0
− 0.08 mm (0 − 0.003 inch)
.
>>E<< H-L SHIFT FORK/H-L CLUTCH SLEEVE
INSTALLATION
Apply MITSUBISHI genuine grease Part number 0101011 or
equivalent to the high-low shift fork lift inserting part at indicated
in drawing. Install the high-low shift fork and the high low clutch
sleeve in the combined state onto the transfer case.
.
AKX00211
MB990938
MB990932
AB
AKX00212
AKX00213
AKX00214
