SYMPTOM PROCEDURES

TSB Revision

SWS SYMPTOM PROCEDURES

54Bb-455

STEP 6. Check dome light connectors F-03 and ETACS-
ECU connector D-222 for damage.
Q: Are dome light connector F-03 and ETACS-ECU

connector D-222 in good condition?
YES : Go to Step 7.
NO :  Repair or replace the connector. Refer to GROUP

00E, Harness Connector Inspection

P.00E-2

. Verify

that the dome light illuminates normally.

AC204174

CONNECTOR : D-222

AB

1

2

3

5

6

4

9 8

121110

13

15 14

16

17

7

19

20

18

JUNCTION BLOCK SIDE

D-222

AC204177

CONNECTOR : F-03

AC

HARNESS SIDE

1
2

F-03

SYMPTOM PROCEDURES

TSB Revision

SWS SYMPTOM PROCEDURES

54Bb-456

STEP 7. Check the wiring harness between dome light
connector F-03 (terminal 2) and ETACS-ECU connector D-
222 (terminal 18).

NOTE: Also check intermediate connector D-26 and junction
block connector D-207 for loose, corroded, or damaged termi-
nals, or terminals pushed back in the connector. If junction
block connector D-207 or intermediate connector D-26 is dam-
aged, repair or replace the damaged component(s) as
described in GROUP 00E, Harness Connector Inspection

P.00E-2

.

Q: Is the wiring harness between dome light connector F-

03 (terminal 2) and ETACS-ECU connector D-222
(terminal 18) in good condition?
YES : Replace the ETACS-ECU. Verify that the dome light

illuminates normally.

NO :  Repair the wiring harness. Verify that the dome light

illuminates normally.

AC204174

CONNECTOR : D-222

AB

1

2

3

5

6

4

9 8

121110

13

15 14

16

17

7

19

20

18

JUNCTION BLOCK SIDE

D-222

AC204177

CONNECTOR : F-03

AC

HARNESS SIDE

1
2

F-03

AC204170

CONNECTOR : D-26

AG

2 3

1

7

6

12

11

8

13

5

4

9 10

AC204173

CONNECTOR : D-207

AB

HARNESS SIDE

1

2

3

4

SYMPTOM PROCEDURES

TSB Revision

SWS SYMPTOM PROCEDURES

54Bb-457

STEP 8. Check the dome light bulb.
Q: Is the dome light bulb in good condition?

YES : Go to Step 9.
NO :  Replace the bulb. Verify that the dome light

illuminates normally.

STEP 9. Check the fusible link (1) line of the power supply
circuit to the dome light. Test at dome light connector F-03.
(1) Disconnect dome light connector F-03 and measure the

voltage available at the wiring harness side of the
connector.

(2) Measure the voltage between terminal 1 and ground.

• The measured value should be approximately 12 volts

(battery positive voltage).

Q: Does the measured voltage correspond with this range?

YES : Replace the dome light. Verify that the dome light

illuminates normally.

NO :  Go to Step 10.

STEP 10. Check dome light connector F-03 for damage.
Q: Is dome light connector F-03 in good condition?

YES : Go to Step 11.
NO :  Repair or replace the connector. Refer to GROUP

00E, Harness Connector Inspection

P.00E-2

. Verify

that the dome light illuminates normally.

AC204177

CONNECTOR : F-03

AC

HARNESS SIDE

1
2

F-03

2

1

ACX01591AB

CONNECTOR F-03
(HARNESS SIDE)

AC204177

CONNECTOR : F-03

AC

HARNESS SIDE

1
2

F-03

SYMPTOM PROCEDURES

TSB Revision

SWS SYMPTOM PROCEDURES

54Bb-458

STEP 11. Check the wiring harness between dome light
connector F-03 (terminal 1) and fusible link (1).

ACX02274

FUSIBLE LINK (1)

AE

BATTERY

AC204177

CONNECTOR : F-03

AC

HARNESS SIDE

1
2

F-03
