SPECIAL TOOLS
TSB Revision
FRONT AXLE
26-9
STEP 4. Check the oil level.
Remove the filler plug and check the gear oil level.
Q: Is the gear oil level more than 8 mm (0.3 inch) below the
bottom of the filler plug hole?
YES : Check the oil leakage from differential carrier, and
repair if necessary. Then, refill Hypoid gear oil API
classification GL-5 or higher, SAE viscosity Number
90, 80W. Then go to Step 5.
NO : There is no action to be taken.
STEP 5. Retest the system.
Q: Is there oil leakage?
YES : Repeat from Step 1.
NO : The procedure is complete.
SPECIAL TOOLS
M1261000600289
AC000439
UPPER LIMIT
LOWER LIMIT
AB
8 mm (0.3 in)
TOOLS
TOOL NUMBER
AND NAME
SUPERSESSION APPLICATION
MB990925
Bearing and oil
seal installer set
MB990925-01 or
General service
tool
• Press-fitting of wheel bearing outer
race MB990935 MB990938
• Press-fitting of oil seal (differential
carrier)
• Press-fitting of drive pinion rear
bearing outer race MB990934
MB990938
• Press-fitting of drive pinion front
bearing outer race MB990936
MB990938
• Oil seal installation (free wheel
clutch) MB990926 MB990938
MB990590 Rear
axle shaft oil
seal remover
A: MB990212
Adapter
B: MB990211
Sliding
hammer
−
• Removal of differential carrier oil seal
• Removal and installation of inner
shaft (Used together with
MB990906)
MB990767 End
yoke holder
MB990767-01
Hub fixing
MB990925
MB990590
A
B
B990767
