M-ASTC DIAGNOSIS TSB Revision MITSUBISHI ACTIVE SKID AND TRACTION CONTROL SYSTEM 35C-89 STEP 19. Measure the voltage in the CAN_L line. Check at CAUTION Before checking CAN bus lines and their interconnected CAUTION When measuring resistance value or voltage in CAN bus rate sensor connector E-126, and measure the voltage at (2) Turn the ignition switch to the "ON" position. CAUTION Always use the test harness when measuring the voltage 122 terminal 20 and body ground. • The voltage should measure 0.5 volts or more, or 4.5 volts or less. Q: Does the voltage measure 0.5 volts or more, or 4.5 volts or less? AC204176 CONNECTOR: E-122 E-122(L) FEMALE SIDE E-122(L) AG 11 22 10 21 9 20 8 19 7 18 6 17 5 16 4 15 3 14 2 13 1 12 AC204175 CONNECTOR: E-126 HARNESS SIDE E-126(GR) E-126(GR) AB FLOOR 1 2 4 3 AC204580 FEMALE CONNECTOR: E-122 AB 11 22 10 21 9 20 8 19 7 18 6 17 5 16 4 15 3 14 2 13 1 12 TEST |
