HYDRAULIC BRAKE BOOSTER (HBB) DIAGNOSIS TSB Revision BASIC BRAKE SYSTEM 35A-93 STEP 2. Check the brake warning light drive circuit at M- the harness connector (component side). (2) Turn the ignition switch to the "ON" position. (3) Connect terminal 81 to a body ground. YES : Replace the M-ASTC-ECU (Refer to GROUP 35C, M- ASTC-ECU NO : Go to Step 3. AC203901 AC204627AP CONNECTOR: E-121 M-ASTC-ECU CONNECTOR E-121 E-121 AC204691AB E-121 HARNESS CONNECTOR: |
