DOOR

TSB Revision

BODY

42-33

AC204218

VIEW A

C

C

A

A

VIEW B

VIEW A

B

B

DOOR LIGHT LENS

POWER WINDOW SWITCH
PANEL ASSEMBLY

VIEW B

SECTION A   A

D

D

E

E

REAR ARM RESTRAINT COVER

CLIP

DOOR TRIM

SECTION B   B

SECTION C   C

SECTION D   D

SECTION E   E

CLIP

DOOR TRIM

DOOR LIGHT
LENS COVER

DOOR LIGHT LENS

DOOR TRIM

CLIP

POWER WINDOW SWITCH
PANEL ASSEMBLY

POWER WINDOW SWITCH
PANEL ASSEMBLY

CLAW

DOOR TRIM

: CLIPS POSITIONS
: CLAW POSITIONS

NOTE

AB

<REAR DOOR>

DOOR

TSB Revision

BODY

42-34

REMOVAL SERVICE POINT

.

<<A>> POWER WINDOW SWITCH ASSEMBLY
There is a clip (driver's side) or a claw (other sides) on the front
of the power window switch assembly. Work from the front side
using special tool MB990784.

.

<<B>> DOOR INSIDE HANDLE COVER REMOVAL
1. Insert the special tool between the inside handle upper part

and the inside handle cover, and then disengage the upper
claw of the inside handle.

2. Disengage the lower claw of the inside handle in the same

manner as for the upper claw.

3. Remove the door trim.
4. Remove the inside handle cover from the door trim.

Y0066CA

ACX00524

POWER WINDOW SWITCH
PANEL ASSEMBLY

MB990784

AC

X0899CA

ACX00525

A

A

INSIDE HANDLE

MB990784

INSIDE HANDLE COVER

SECTION A   A

CLAW

INSIDE
HANDLE

CLAW

INSIDE
HANDLE
COVER

AB

DOOR

TSB Revision

BODY

42-35

INSTALLATION SERVICE POINT

.

>>A<< WATERPROOF FILM INSTALLATION

CAUTION

Be sure to apply the sealant below the inner panel water
drain holes so as not to plug them.
1. Install the escutcheon and the clip to the regulator handle.
2. Fully close the front door glass, and install the regulator

handle so that it faces as shown in the illustration.

X0084CA

X0128CA

ACX00526

INNER PANEL WATER DRAIN HOLE

<FRONT DOOR>

<REAR DOOR>

WATERPROOF FILM

WATERPROOF FILM

AB

DOOR

TSB Revision

BODY

42-36

INSPECTION

M1421007600354

POWER WINDOW SWITCH CONTINUITY CHECK

POWER WINDOW MAIN SWITCH CHECK

NOTE: *:Set switch to UNLOCK position.
POWER WINDOW SUB SWITCH CHECK

SWITCH POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

FRONT (LH)

UP

5

− 7, 3 − 8

Less than 2
ohms

OFF

3

− 7, 3 − 8,

7

− 8

DOWN

5

− 8, 3 − 7

FRONT (RH)

UP

5

− 14, 1 − 3*

OFF

1

− 14, 1 − 3*,

3

− 14

DOWN

1

− 5, 3 − 14*

REAR (LH)

UP

5

− 13, 3 − 6*

OFF

6

− 13, 3 − 6*,

3

− 13*

DOWN

5

− 6, 3 − 13*

REAR (RH)

UP

2

− 5, 3 − 9*

OFF

2

− 9, 2 − 3*,

3

− 9*

DOWN

5

− 9, 2 − 3*

SWITCH POSITION

TESTER
CONNECTION

SPECIFIED
CONDITION

FRONT UP

5

− 8, 6 − 10

Less than 2
ohms

OFF

4

− 8, 6 − 10

DOWN

5

− 6, 4 − 8

REAR (LH)

UP

4

− 6, 1 − 2

OFF

5

− 6, 1 − 2

DOWN

1

− 4, 5 − 6

REAR (RH)

UP

4

− 6, 1 − 2

OFF

5

− 6, 1 − 2

DOWN

1

− 4, 5 − 6

7

6

5

4

3

2

1

14

13

12

11

10

9

8

ACX02412

5

4

3

2

1

10

9

8

7

6

ACX02413

ACX00538

AC000121

<FRONT>

<REAR>
