Montero 1) Disconnect door lock cylinder switch connector. Set door lock switch in UNLOCK position. Continuity should be present between switch terminals No. 1 (Black/Blue wire) and No. 2 (Black wire). 2) Set door lock switch in LOCK position. Continuity should be present between switch terminals No. 2 (Black wire) and No. 3 (Black/Red wire). Continuity should not be present in any of the terminals with switch in OFF position. 3000GT (Left Side) 1) Disconnect door lock cylinder switch connector. Set door lock switch in LOCK position. Continuity should be present between switch terminals No. 2 (Black wire) and No. 3 (Light Green/White wire). 2) Set door lock switch in UNLOCK position. Continuity should be present between switch terminals No. 1 (Green/Blue wire) and No. 2 (Black wire). Continuity should not be present in any of the terminals with switch in OFF position. 3000GT (Right Side) 1) Disconnect door lock cylinder switch connector. Set door lock switch in LOCK position. Continuity should be present between switch terminals No. 1 (Green/White wire) and No. 2 (Black wire). 2) Set door lock switch in UNLOCK position. Continuity should be present between switch terminals No. 2 (Black wire) and No. 3 (Green/White wire). Continuity should not be present in any of the terminals with switch in OFF position. DOOR LOCK SWITCH Main Switch (Montero) 1) Remove door lock switch from door. Set door switch in LOCK position. Continuity should be present between switch terminals No. 5 and 12. See Fig. 1. 2) Set door lock switch in UNLOCK position. Continuity should be present between switch terminals No. 10 and 12. 3) Set door lock switch in OFF position. Continuity should not be present in any terminals. Replace main door lock switch if continuity is not as specified. Main Switch (3000GT W/Power Window) 1) Disconnect door lock switch connector. Set door lock switch in LOCK position. Continuity should be present between switch terminals No. 6 and 7. See Fig. 3. 2) Set door lock switch in UNLOCK position. Continuity should be present between switch terminals No. 5 and 6. Continuity should not be present in any of the terminals with switch in OFF position. Main Switch (3000GT W/O Power Window) 1) Disconnect door lock switch connector. Set door lock switch in LOCK position. Continuity should be present between switch terminals No. 2 and 3. See Fig. 5. 2) Set door lock switch in UNLOCK position. Continuity should be present between switch terminals No. 2 and 5. Continuity should not be present in any of the terminals with switch in OFF position. Sub-Switch (Montero) 1) Remove switch from door. Set door switch in LOCK position. Continuity should be present between switch terminals No. 1 and 2. See Fig. 2. 2) Set door lock switch in UNLOCK position. Continuity should be present between switch terminals No. 2 and 3. 3) Set door lock switch in OFF position. Continuity should |
