MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS
TSB Revision
MULTIPORT FUEL INJECTION (MFI) <2.4L ENGINE>
13A-773
STEP 7. Using scan tool MB991958, check data list item 27:
Power Steering Pressure Switch.
CAUTION
To prevent damage to scan tool MB991958, always turn the
ignition switch to the "LOCK" (OFF) position before con-
necting or disconnecting scan tool MB991958.
(1) Connect scan tool MB991958 to the data link connector.
(2) Start the engine and run at idle.
(3) Set scan tool MB991958 to the data reading mode for item
27, Power Steering Pressure Switch.
• If the steering wheel is not turned while idling, "OFF" will
be displayed.
• If the steering wheel is turned while idling, "ON" will be
displayed.
(4) Turn the ignition switch to the "LOCK" (OFF) position.
Q: Is the switch operating properly?
YES : The inspection is complete.
NO : Retry the troubleshooting.
DTC P0606: Powertrain Control Module Main Processor Malfunction
.
TECHNICAL DESCRIPTION
• Throttle actuator control processor checks the
PCM for abnormal conditions.
.
DESCRIPTIONS OF MONITOR METHODS
No watch dog pulse is detected.
.
MONITOR EXECUTION
Continuous
.
MONITOR EXECUTION CONDITIONS (Other
monitor and Sensor)
Other Monitor (There is no temporary DTC stored
in memory for the item monitored below)
• Not applicable
Sensor (The sensor below is determined to be
normal)
• Not applicable
.
DTC SET CONDITIONS
Check Conditions
• Ignition switch is "ON" position.
Judgement Criteria
• No surveillance pulse signals should be input for
0.5 second.
.
OBD-II DRIVE CYCLE PATTERN
None.
.
TROUBLESHOOTING HINTS (The most likely
causes for this code to be set are:)
• PCM failed.
AK303804AB
MB991910
DATA LINK
CONNECTOR
MB991824
MB991827
