TIMING BELT TSB Revision ENGINE OVERHAUL <3.8L ENGINE> 11D-13 >>B<< CRANKSHAFT SENSING BLADE/CRANKSHAFT sprocket, sensing blade, and spacer. 3. Align the location of pin and pin hole, and then apply equal force in the direction of the arrow. CAUTION Do not bend the sensing blade when installing sprocket. . >>C<< AUTO-TENSIONER INSTALLATION the rod is aligned with hole B in the cylinder. 3. Insert a wire [1.4 mm (0.055 inch) in diameter] into the set holes. This auto-tensioner setting wire will be used during 4. Unclamp the auto-tensioner from the vise. . >>D<< TIMING BELT INSTALLATION CAUTION Do not turn the camshaft when the piston in No.1 cylinder washer, and then tighten the crankshaft bolt. 2. Align the timing mark on the crankshaft sprocket with the timing mark on the oil pump case, and then rotate the AK101687 CLEAN DEGREASE CRANKSHAFT CRANKSHAFT CRANKSHAFT SENSING BLADE CRANKSHAFT OIL PUMP CASE AC AK201830AD PIN HOLE PIN AK204321AB A B AKX00632 MD998769 CRANKSHAFT AB TIMING MARK |
