FRONT AXLE HUB ASSEMBLY TSB Revision FRONT AXLE 26-11 2. Turn the bolt and knob as necessary to make the jaws of special tool parallel, tighten the bolt by hand and confirm 3. Tighten the bolt with a wrench to disconnect the lower arm ball joint, tie rod end and remove the self locking nut. . <<E>> FRONT WHEEL HUB ASSEMBLY REMOVAL MB990767 to push out the drive shaft from the hub and 2. If the front wheel hub is seized, remove the knuckle together with front wheel hub and fix them with a vise. 3. Hang the drive shaft on the vehicle body with a rope. 4. Use special tools MB990244, MB991354 and MB990211 to pull out the front wheel hub from the knuckle. INSTALLATION SERVICE POINT . >>A<<WASHER/ DRIVE SHAFT NUT INSTALLATION CAUTION Before securely tightening the drive shaft nuts, make sure direction. 2. Using special tool MB990767, tighten the drive shaft nut to the specified torque. Tightening torque: 226 ± 29 N⋅m (167 ± 21 ft-lb) AC106821 KNOB PARALLEL BOLT CORRECT WRONG AC AC201827 MB990244 MB991354 MB990242 MB990767 AD AC210309AD MB990211 MB991354 MB990244 AC210244AB MB990767 WASHER |
