AUTO-CRUISE CONTROL TSB Revision ENGINE AND EMISSION CONTROL 17-27 (5) Measure the ground voltage between special tool 23-pin connector (without red tape) terminal 28 (PCM connector B-20 terminal 28) and ground. (6) Turn the "CRUISE" (MAIN) switch to the "OFF" position. the body-side harness connector. (9) Reconnect all the connectors to the PCM. YES : Go to Step 12 . STEP 11. Check PCM connector B-20 for loose, corroded Q: Are the connector and terminals in good condition? YES : Install the air bag module (driver’s side) (Refer to GROUP 52B, Air Bag Modules and Clock Spring NO : Repair or replace the faulty connector (Refer to GROUP 00E, Harness Connector Inspection ), and install the air bag module (driver’s side) (Refer to GROUP 52B, Air Bag Modules and Clock AC209615 AB SPECIAL TOOL 23-PIN AC305710 B-20 HARNESS CONNECTOR: COMPONENT SIDE AD B-20 CONNECTOR: B-20 AIR CLEANER PCM |
