BASE ENGINE

ENGINE <2.4L ENGINE>

11A-13

Oil Pan

The oil pan design improves rust prevention by using
galvanized sheet steel; prevents agitation due to the
crankshaft; reduces oil air ration and rotational resis-
tance of the crankshaft by using a baffle plate
installed to the lower side of the bearing cap.

AK300823 AD

OIL CUT GROOVE

OIL DRAIN HOLE

BAFFLE PLATE

NOTES

11B-1

GROUP 11B

ENGINE

 <3.8L ENGINE>

CONTENTS

GENERAL DESCRIPTION. . . . . . . . .

11B-2

BASE ENGINE . . . . . . . . . . . . . . . . . .

11B-3

GENERAL DESCRIPTION

ENGINE <3.8L ENGINE>

11B-2

GENERAL DESCRIPTION

M2112000100329

The related main body (cylinder block, cylinder head,
piston and connecting rod) of 6G75-SOHC Engine
assembled on GALANT in a new model vehicle is the
same as that of 6G75-SOHC Engine assembled on
ENDEAVOR. The other components are based on
the 6G72-SOHC Engine assembled on GALANT.
The changes are applied as follows:

•

Change of installation location for oil filter bracket
and addition of cover.

.

MAJOR SPECIFICATIONS

ITEMS

SPECIFICATIONS

Total displacement cm

3

 (cu in)

3828 (233.6)

Bore

×

 Stroke mm (in)

95 (3.74)

×

 90 (3.54)

Compression ratio

10.0

Combustion chamber

Pentroof type

Camshaft arrangement

SOHC

Valve timing

Intake Open

7

°

 BTDC

Intake Close

61

°

 ABDC

Exhaust Open

61

°

 BBDC

Exhaust Close

15

°

 ATDC

Maximum output kW/r/min (HP/r/min)

171/5250 (230/5250)

Maximum torque N

⋅

m/r/min (lbs-ft/r/min)

339/4000 (250/4000)

Fuel system

Electronic-controlled multiport fuel injection

Rocker arm

Roller type
