REAR COMBINATION LIGHT

TSB Revision

CHASSIS ELECTRICAL

54A-123

REAR COMBINATION LIGHT

DIAGNOSIS

M1542000701377

The taillights and turn-signal lights are controlled by
the Simplified Wiring System (SWS). For trouble-
shooting, refer to GROUP 54B, SWS Diagnosis

P.54B-59

.

REAR COMBINATION LIGHT

REMOVAL AND INSTALLATION

M1542003900463

AC307165

AB

1

CLIP

SECTION A – A

1

3

2

A

A

4.9 ± 0.7 N·m
44 ± 6 in-lb

NOTE
          : CLIP POSITION

REMOVAL STEPS

•

TRUNK ROOM FLOOR BOARD,
REAR END TRIMS (REFER TO
GROUP 52A, TRIM

P.52A-10

.)

1.

REAR COMBINATION LIGHT

2.

SOCKET ASSEMBLY

3.

BULB

REMOVAL STEPS (Continued)

DOME LIGHT

TSB Revision

CHASSIS ELECTRICAL

54A-124

DOME LIGHT

DIAGNOSIS

M1542000701388

The dome light is controlled by the Simplified Wiring
System (SWS). For troubleshooting, refer to GROUP
54B, SWS Diagnosis

P.54B-59

.

SPECIAL TOOLS

M1542000601024

DOME LIGHT

REMOVAL AND INSTALLATION

M1542006300028

TOOL

TOOL NUMBER AND
NAME

SUPERSESSION

APPLICATION

MB990784
Ornament remover

General service
tool

Removal of map light,
cover etc.

MB990784

AC307690

AB

1

2

3

4

5

6

7

9

8

A

A

A

A

A

A

NOTE
          : CLIP POSITION

SECTION A – A

1, 3

CLIP

HEADLINING

OVERHEAD
CONSOLE
BRACKET

DOME LIGHT

TSB Revision

CHASSIS ELECTRICAL

54A-125

REMOVAL SERVICE POINT

.

<<A>> COVER REMOVAL
Use special tool MB990784 to remove the cover as shown in
the illustration.

MAPLIGHT ASSEMBLY
REMOVAL STEPS

1.

MAP LIGHT ASSEMBLY

2.

BULB
OVERHEAD CONSOLE
ASSEMBLY REMOVAL STEPS

3.

OVERHEAD COSOLE ASSEMBLY

4.

BULB

REAR DOME LIGHT ASSEMBLY
REMOVAL STEPS

<<A>>

5.

COVER

6.

REAR DOME LIGHT

7.

BULB
TRUNK LIGHT REMOVAL STEPS

8.

TRUNK LIGHT

9.

BULB

AC307746 AB

A

A

MB990784

MB990784

COVER

SECTION A – A

FRONT OF VEHICLE

LICENSE PLATE LIGHT

TSB Revision

CHASSIS ELECTRICAL

54A-126

LICENSE PLATE LIGHT

REMOVAL AND INSTALLATION

M1542004200207

AC307186

2

3

1

AB

1.7 ± 0.3 N·m
15 ± 3 in-lb

REMOVAL STEPS

1. LICENSE PLATE LIGHT ASSEMBLY
2. SOCKET
3. BULB
