INSTRUMENT PANEL ASSEMBLY

TSB Revision

INTERIOR

52A-3

INSTRUMENT PANEL ASSEMBLY

REMOVAL AND INSTALLATION

M1521001700457

CAUTION

• For removal and installation of the passenger's side air bag module, always observe the service

procedures described in GROUP 52B, Air Bag Module and Clock Spring

P.52B-368

.

• Refer to GROUP 52B, SRS Service Precautions

P.52B-26

 and Air bag Module and Clock Spring

P.52B-368

 before removing the passenger side air bag module.

• Do not subject the SRS-ECU to any shocks when removing or installing the instrument panel.

The following bolts and screws are used for installing the instrument panel. Bolts and screws are indicated as
marks shown in the illustration in the sections of "Removal and Installation" and "Disassembly and Assem-
bly."

NAME

SYMBOL

SIZE (D

× L) mm

COLOR

SHAPE

TAPPING SCREW

a

5

× 12

BLACK

b

5

× 16

-

c

5

× 20

-

d

5

× 20

BLACK

e

6

× 16

GREEN

f

8

× 15

-

WASHER
ASSEMBLY BOLT

g

6

× 16

-

h

6

× 25

-

i

6

× 16

-

AC104450

AC104448

AC104426

AC307531

AC104416

AC104417

INSTRUMENT PANEL ASSEMBLY

TSB Revision

INTERIOR

52A-4

AC306858

2

1

3

4

5

6

7

8

9

10

11

12

13

14

14

14

15

16

17

18

19

20

21

22

23

25

16

17

18

19

AB

a

b

b

b

b

b

b

b

b

b

b

b

b

b

b

c

d

e

e

e

e

f

i

i

i

i

i

b

b

h

24

24

REMOVAL STEPS

1.

GLOVEBOX ASSEMBLY

2.

INSTRUMENT PANEL PARCEL
BOX

3.

GLOVEBOX LOCK

•

HOOD LOCK RELEASE HANDLE
(REFER TO GROUP 42, HOOD

P.42-8

.)

4.

INSTRUMEN LOWER PANEL

5.

INSTURMENT CENTER PANEL
ASSEMBLY

REMOVAL STEPS (Continued)

INSTRUMENT PANEL ASSEMBLY

TSB Revision

INTERIOR

52A-5

6.

RADIO AND CD PLAYER,
ACCESSORY BOX ASSEMBLY

7.

RADIO, CD PLAYER AND CD
CHANGER ASSEMBLY

8.

CONSOLE METER HOOD

9.

PASSENGER’S AIR BAG OFF
INDICATOR LIGHT

10. PASSENGER’S SEAT BELT

WARNING LIGHT

11. MULTI-CENTER DISPLAY

ASSEMBLY

12. INSTRUMENT PANEL CLOCK

HOLE BOX <DE>

13. CENTER CONSOLE ASSEMBLY
14. INSTURMENT PANEL GARNISH
15. COMBINATION METER

ASSEMBLY

•

FRONT PILLAR TRIM (REFER TO

P.52A-10

.)

16. FRONT SPEAKER GARNISH
17. TWEETER
18. INSTRUMENT PANEL SIDE

COVER

19. INSTRUMETN PANEL SIDE AIR

OUTLET

•

AIR BAG MODULE ASSEMBLY
(DRIVER’S SIDE) (REFER TO
GROUP 52B, AIR BAG MODULE
AND CLOCK SPRING

P.52B-368

.)

•

STEERING WHEEL ASSEMBLY
(REFER TO GROUP 37,
STEERING WHEEL

P.37A-27

.)

REMOVAL STEPS (Continued)

20. STEERING COLUMN COVER

<<A>>

•

CLOCK SPRING CONNECTOR

<<A>>

•

COLUMN SWITHC CONNECTOR

•

CLOCK SPRING AND COLUMN
SWITCH ASSEMBLY (REFER TO
GROUP 37, STEERING SHAFT

P.37A-29

.)

21. INTERIOR TEMPERATURE

SENSOR <VEHICLES WITH
AUTOMATIC AIR
CONDITIONING> (GROUP 55B,
SENSORS

P.55B-25

.)

22. INSTRUMENT PANEL FRONT

END GARNISH

23. PHOTO SENSOR <VEHICLES

WITH AUTOMATIC AIR
CONDITIONING> (GROUP 55B,
SENSORS

P.55B-25

.)

24. STAY
•

FLOOR CONSOLE ASSEMBLY
(REFER TO

P.52A-9

.)

•

COWL SIDE TRIM (REFER TO

P.52A-10

.)

<<A>>

•

AIR BAG MODULE CONNECTOR
(PASSENGER’S SIDE) (REFER
TO GROUP 52B, AIR BAG
MODULE AND CLOCK SPRING

P.52B-368

.)

25. INSTRUMENT PANEL ASSEMBLY

REMOVAL STEPS (Continued)

INSTRUMENT PANEL ASSEMBLY

TSB Revision

INTERIOR

52A-6

CLIP AND CLAW POSITIONS

AC307556 AB

NOTE
(1)          : CLIP POSITION
(2)          : CLAW POSITION

SECTION A – A

SECTION E – E

SECTION F – F

SECTION G – G

SECTION H– H

SECTION K – K

SECTION L – L

SECTION J – J

SECTION I – I

SECTION B – B

SECTION C – C

SECTION D – D

A

A

C

B

B

C

D

D

E

E

F

F

H

H

I

I

G

G

J

J

K

K

L

L

CLIP

CONSOLE METER
HOOD

CLIP

INSTRUMENT PANEL
FRONT  END GARNISH

FRONT SPEAKER
GARNISH

CLIP

CLIP

INSTURMENT
PANEL SIDE
AIR OUTLET

CLIP

INSTRUMENT
CENTER PANEL
ASSEMBLY

CLIP

INSTRUMENT
PANEL GARNISH

CLIP

INSTURMENT
LOWER PANEL

STEERING
COLUMN
COVER

CLAW

INSTRUMENT
CENTER PANEL
ASSEMLBY

CLAW

CLIP

INSTRUEMTN
PANEL PARCEL
BOX

CLIP

INSTRUMENT PANLE
SIDE COVER

CLAW

INSTRUEMTN
PANEL SIDE
COVER
