MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) <3.8L ENGINE> 13B-241 STEP 3. Measure the power supply voltage at right bank (1) Disconnect the connector B-09 and measure at the harness side. (2) Turn the ignition switch to the "ON" position. (3) Measure the voltage between terminal No. 1 and ground. • Voltage should be battery positive voltage. (4) Turn the ignition switch to the "LOCK" (OFF) position. present? 1 2 3 4 AK303048 B-09 (B) CONNECTOR: B-09 THROTTLE BODY RIGHT BANK AB HARNESS AK303060 B-09 HARNESS 1 2 3 4 AB |
