Mitsubishi Galant (2004+). Manual - part 107

WINDSHIELD WIPER AND WASHER

TSB Revision

CIRCUIT DIAGRAMS

90-187

JOINT
CONNECTOR (3)

DATA LINK
CONNECTOR

ETACS-ECU

ABS-ECU OR
ABS/TCL-ECU

DEFOGGER AND DOOR MIRROR HEATER

TSB Revision

CIRCUIT DIAGRAMS

90-188

DEFOGGER AND DOOR MIRROR HEATER

M1901013500445

TAILLIGHT
RELAY

FRONT-ECU

IGNITION
SWITCH (IG2)

FUSIBLE
LINK

1

RELAY
BOX

JOINT
CONNECTOR
(1)

JUNCTION
BLOCK

RHEOSTAT

DEFOGGER

CHOKE
COIL

JUNCTION
BLOCK

DEFOGGER
RELAY

A/C
-ECU

NOTE

: MANUAL AIR CONDITIONING
  SYSTEM <LOW>
: MANUAL AIR CONDITIONING
  SYSTEM <MIDDLE> OR
  AUTOMATIC AIR CONDITIONING
  SYSTEM

·AUDIO SYSTEM
·ELECTRONIC BRAKE-
 FORCE DISTRIBUTION
 (EBD) AND ANTI-LOCK
 BRAKING SYSTEM (ABS)
 <VEHICLES WITH
 TRACTION CONTROL (TCL)>
·FOG LIGHT
·GLOVE BOX LIGH
·HEATED SEAT
·INVECS-II 4A/T
·METER AND GAUGE
·MULTI CENTER
 DISPLAY
·RHEOSTAT
·SUPPLEMENTAL
 RESTRAINT
 SYSTEM (SRS)
·TURN-SIGNAL
 LIGHT AND
 HAZARD WARNING
 LIGHT

DEFOGGER AND DOOR MIRROR HEATER

TSB Revision

CIRCUIT DIAGRAMS

90-189

<WITH DOOR MIRROR HEATER>

JUNCTION
BLOCK

(FUSE     )

19

REMOTE
CONTROLLED
MIRROR (LH)

REMOTE
CONTROLLED
MIRROR (RH)

MIRROR
HEATER

MIRROR
HEATER

DEFOGGER AND DOOR MIRROR HEATER

TSB Revision

CIRCUIT DIAGRAMS

90-190

DEFOGGER AND DOOR MIRROR HEATER (CONTINUED)

<WITH MULTI CENTER DISPLAY (MIDDLE) >

A/C-ECU

JOINT
CONNECTOR (3)

DATA LINK
CONNECTOR

MULTI CENTER DISPLAY UNIT

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW
SB : SKY BLUE     BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET
