MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L ENGINE>

13A-1033

INSPECTION PROCEDURE 29: Fuel pump system

1 2 3

4

4 5 6

1 2 3

5

1

3

2

4 5 6

1

6

4 5

11

10

12 13 14

8 9

7

2 3

1

6

4 5

11

10

1213

15

17

16

14

19

18

8 9

7

20

2 3

2122 23 2425 26 27 28

3 4

1 2

3 4

1 2

1 2 3 4

5 6 7

15

14

13

12

11

10

9

8

1 2 3 4

5 6 7

8 9 10 11

12 13 14

15 16 17 18

AK303942

WHITE

WHITE

VIOLET

VIOLET

BLA

CK

IG2

ST

LOCK

ACC

IG1

C-308

JUNCTION
BLOCK

R

IGNITION
SWITCH

RELAY
BOX

POWERTRAIN CONTROL
MODULE (PCM)

FUEL
PUMP
RELAY (1)
C-210

FUEL
PUMP
RELAY (2)
C-208

FUEL PUMP
MODULE

16

2

D-18

(MU802058)

1

14

11

M

WHITE-BLA

CK

BLA

CK

5

4

B-19

Fuel Pump Circuit

OFF

4

2

2

6

1

3

OFF

ON

ON

1

2

4

3

BATTERY

C-214

MU801857

C-29

C-208

C-210

C-215

MU801331

6

BLUE-WHITE

C-204

C-211

C-211

C-211

24

15A

17

7.5A

C-204

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L ENGINE>

13A-1034

AK303927AB

CONNECTORS: C-208, C-210

FUEL PUMP RELAY (1)

FUEL PUMP
RELAY (2)

C-210

C-208

AK303918AB

C-29

CONNECTOR: C-29

AK303839AC

CONNECTOR: D-18

SERVICE
HOLE

 FUEL PUMP MODULE

D-18 (GR)

AK303924AB

CONNECTOR: C-214

C-214

AK303153

4 3 2 1

7 6 5

9 8

11 10

14 13 12

18 17 16 15

CONNECTOR: B-19

PCM

AB

AIR CLEANER

HARNESS CONNECTOR:
COMPONENT SIDE

B-19 (B)

AK303925AB

CONNECTOR: C-215

C-215

AK303923AB

CONNECTOR: C-308

C-308

AK303915AB

CONNECTOR: C-211

C-211

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L ENGINE>

13A-1035

.

CIRCUIT OPERATION

• Battery positive voltage is applied to the fuel

pump relay 1 (terminal No. 3) from the ignition
switch-IG.
Ground is provided through terminal No. 2 to
chassis ground.

• When the ignition switch is turned to the "ON"

position, the battery positive voltage is applied to
the fuel pump relay 2 (terminal No. 1) from the
fuel pump relay 1 (terminal No. 1).

• Battery positive voltage is applied to the fuel

pump relay 2 (terminal No. 3) from the ignition
switch-IG.

• During cranking and while the engine is running,

the PCM turns the power transistor in the PCM
ON to ground the fuel pump relay 2 coil. With this,
the fuel pump relay turns ON, and the battery
positive voltage is supplied to the fuel pump from
the fuel pump relay 2 (terminal No. 4).

.

TROUBLESHOOTING HINTS (The most likely
causes for this code to be set are:)

• Malfunction of the fuel pump relay.

• Malfunction of the fuel pump.

• Improper connector contact, open or short-circu-

lated harness wire.

• Malfunction of the PCM.

DIAGNOSIS

Required Special Tools:

• MB991958: Scan Tool (MUT-III Sub Assembly)

• MB991824: V.C.I.

• MB991827: USB Cable

• MB991910: Main Harness A

AK303929AB

CONNECTOR: C-204

C-204

MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS

TSB Revision

MULTIPORT FUEL INJECTION (MFI) <2.4L ENGINE>

13A-1036

STEP 1. Using scan tool MB991958, check actuator test
item 07: Fuel Pump.

CAUTION

To prevent damage to scan tool MB991958, always turn the
ignition switch to the "LOCK" (OFF) position before con-
necting or disconnecting scan tool MB991958.
(1) Connect scan tool MB991958 to the data link connector.
(2) Turn the ignition switch to the "ON" position.
(3) Set scan tool MB991958 to the actuator test mode for item

07, Fuel Pump.

• An operation sound of the fuel pump should be heard.

(4) Turn the ignition switch to the "LOCK" (OFF) position.
Q: Is the fuel pump operating properly?

YES : That this malfunction is intermittent. Refer to GROUP

00, How to Use Troubleshooting/Inspection Service
Points

P.00-6

.

NO :  Go to Step 2.

STEP 2. Check harness connector C-210 at fuel pump relay
1 and harness connector C-208 at fuel pump relay 2 for
damage.
Q: Is the harness connector in good condition?

YES : Go to Step 3.
NO :  Repair or replace it. Refer to GROUP 00E, Harness

Connector Inspection

P.00E-2

. Then confirm that the

malfunction symptom is eliminated.

AK303804AB

MB991910

DATA LINK
CONNECTOR

MB991824

MB991827

2 1

3

4

AK303930AB

CONNECTORS: C-208, C-210

JUNCTION BLOCK
TRIANGLE MARK

C-208

HARNESS CONNECTOR:
COMPONENT SIDE

C-210
