Mitsubishi Galant (2004+). Manual - part 103

MANUAL AIR CONDITIONING SYSTEM <MIDDLE>

TSB Revision

CIRCUIT DIAGRAMS

90-171

NOTES

AUTOMATIC AIR CONDITIONING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-172

AUTOMATIC AIR CONDITIONING SYSTEM

M1901005600287

·AUDIO SYSTEM
·AUTO-CRUISE
 CONTROL SYSTEM
·BRAKE WARNING
 LIGHT, OIL PRESSURE
 WARNING LIGHT,
 FUEL WARNING LIGHT
·CENTRAL DOOR
 LOCKING SYSTEM
·CHARGING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·DOOR AJAR WARNING
 TONE ALARM
·ELECTRONIC BRAKE-
 FORCE DISTRIBUTION
 (EBD) AND ANTI-LOCK
 BRAKING SYSTEM (ABS)
·ENGINE IMMOBILIZER
 SYSTEM
·FOG LIGHT
·FRONT DOME LIGHT,
 REAR DOME LIGHT,
 TRUNK LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·HEADLIGHT
·INVECS-II 4A/T
·LIGHTING MONITOR
 TONE ALARM
·METER AND GAUGE
·MFI SYSTEM
·MULTI CENTER DISPLAY
·SEAT BELT WARNING
 TONE ALARM
·SUPPLEMENTAL
 RESTRAINT SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
 FRONT SIDE MARKER LIGHT
 AND LICENSE PLATE LIGHT
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·VANITY MIRROR LIGHT
·WINDSHIELD WIPER
 AND WASHER

·FOG LIGHT
·HEADLIGHT
·REAR WIPER
 AND WASHER
·TAILLIGHT,
 POSITION LIGHT,
 FRONT SIDE
 MARKER LIGHT
 AND LICENSE
 PLATE LIGHT
·TURN-SIGNAL
 LIGHT AND
 HAZARD
 WARNING LIGHT
·WINDSHIELD
 WIPER AND
 WASHER

BATTERY

FRONT-ECU

TAILLIGHT
RELAY

JOINT
CONNECTOR (1)

JUNCTION
BLOCK

RELAY
BOX

·AUDIO SYSTEM
·ELECTRONIC BRAKE-
 FORCE DISTRIBUTION
 (EBD) AND ANTI-LOCK
 BRAKING SYSTEM (ABS)
 <VEHICLES WITH
 TRACTION CONTROL (TCL)>
·FOG LIGHT
·GLOVE BOX LIGHT
·HEATED SEAT
·INVECS-II 4A/T
·METER AND
 GAUGE
·MULTI CENTER
 DISPLAY
·RHEOSTAT
·SUPPLEMENTAL
 RESTRAINT SYSTEM
 (SRS)
·TURN-SIGNAL
 LIGHT AND HAZARD
 WARNING LIGHT

POWER SUPPLY

AUTOMATIC AIR CONDITIONING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-173

·CENTRAL DOOR
 LOCKING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·FRONT DOME LIGHT,
 REAR DOME LIGHT,
 TRUNK LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·MULTI CENTER
 DISPLAY
·WINDSHELD WIPER
 AND WASHER

IGNITION
SWITCH (ACC)

RELAY
BOX

JOINT
CONNECTOR (2)

A/C-ECU

POWER SUPPLY

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE
BR :BROWN     O : ORANGE     GR : GRAY     R : RED     W : WHITE
SB : SKY BLUE     P : PINK      Y : YELLOW     V : VIOLET

WINDSHIELD WIPER
AND WASHER

AUDIO SYSTEM

·CENTRAL DOOR
 LOCKING SYSTEM
·CONTROLLER
 AREA NETWORK
 (CAN)
·FRONT DOME LIGHT,
 REAR DOME LIGHT,
 TRUNK LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·REMOTE
 CONTROLLED
 MIRROR

AUTOMATIC AIR CONDITIONING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-174

AUTOMATIC AIR CONDITIONING SYSTEM (CONTINUED)

BATTERY

FUSIBLE LINK

FUSIBLE
LINK

CONDENSER
FAN RELAY

CONDENSER
FAN MOTOR

RADIATOR
FAN MOTOR

FAN CONTROL
RELAY

GROUNDING
CONNECTOR

IGNITION
SWITCH (IG2)

JUNCTION
BLOCK
