Mitsubishi Galant (2004+). Manual - part 87

FRONT DOME LIGHT, REAR DOME LIGHT, TRUNK LIGHT AND IGNITION KEY HOLE ILLUMINATION LIGHT

TSB Revision

CIRCUIT DIAGRAMS

90-107

RELAY BOX
(FUSE     )

22

JOINT
CONNECTOR (2)

COMBINATION
METER

JOINT
CONNECTOR (3)

DATA LINK
CONNECTOR

FRONT DOME LIGHT, REAR DOME LIGHT, TRUNK LIGHT AND IGNITION KEY HOLE ILLUMINATION LIGHT

TSB Revision

CIRCUIT DIAGRAMS

90-108

FRONT DOME LIGHT, REAR DOME LIGHT, TRUNK LIGHT AND IGNITION KEY HOLE ILLUMINATION
LIGHT (CONTINUED)

FRONT
DOOR
SWITCH
(LH)

REAR
DOOR
SWITCH
(LH)

FRONT
DOOR
SWITCH
(RH)

REAR
DOOR
SWITCH
(RH)

FRONT DOME LIGHT, REAR DOME LIGHT, TRUNK LIGHT AND IGNITION KEY HOLE ILLUMINATION LIGHT

TSB Revision

CIRCUIT DIAGRAMS

90-109

FRONT
DOOR LOCK
ACTUATOR
(LH)

ETACS-
ECU

JUNCTION
BLOCK

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW
SB : SKY BLUE     BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET

JUNCTION BLOCK SIDE

KEY
REMINDER
SWITCH

WHEN KEY
IS REMOVED

GLOVE BOX LIGHT

TSB Revision

CIRCUIT DIAGRAMS

90-110

GLOVE BOX LIGHT

M1901002200343

·AUDIO SYSTEM
·AUTOMATIC AIR
 CONDITIONING
 SYSTEM
·DEFOGGER AND
 DOOR MIRROR
 HEATER
·ELECTRONIC BRAKE-
 FORCE DISTRIBUTION
 (EBD) AND ANTI-LOCK
 BRAKING SYSTEM (ABS)
 <VEHICLES WITH
 TRACTION CONTROL (TCL)>
·FOG LIGHT
·HEATED SEAT
·INVECS-II 4A/T
·MANUAL AIR
 CONDITIONING
 SYSTEM
·METER AND GAUGE
·MULTI CENTER
 DISPLAY
·RHEOSTAT
·SUPPLEMENTAL
 RESTRAINT
 SYSTEM (SRS)
·TURN-SIGNAL LIGHT
 AND HAZARD WARNING
 LIGHT

TAILLIGHT
RELAY

FRONT-ECU

RELAY
BOX

JOINT
CONNECTOR (1)

JUNCTION
BLOCK

GLOVE BOX
LIGHT

WIRE COLOR CODE
B : BLACK     SB : SKY BLUE
BR : BROWN     LG : LIGHT GREEN
G : GREEN P : PINK     GR : GRAY
R : RED     L : BLUE     Y : YELLOW
V : VIOLET     W : WHITE     O : ORANGE
