Mitsubishi Galant (2004+). Manual - part 83

TAILLIGHT, POSITION LIGHT, FRONT SIDE MARKER LIGHT AND LICENSE PLATE LIGHT

TSB Revision

CIRCUIT DIAGRAMS

90-91

IGNITION
SWITCH (IG2)

JUNCTION
BLOCK

JOINT
CONNECTOR (1)

RELAY
BOX

POWER
SUPPLY

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW
SB : SKY BLUE     BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET

TAILLIGHT, POSITION LIGHT, FRONT SIDE MARKER LIGHT AND LICENSE PLATE LIGHT

TSB Revision

CIRCUIT DIAGRAMS

90-92

TAILLIGHT, POSITION LIGHT, FRONT SIDE MARKER LIGHT AND LICENSE PLATE LIGHT (CONTIN-
UED)

(FUSE     )

RELAY BOX

FRONT
COMBINATION
LIGHT (LH)

REAR
COMBINATION
LIGHT (LH)

LICENSE
PLATE
LIGHT

21

NOTE

: WITH TRUNK LID TYPE
  HIGH-MOUNTED STOPLIGHT
: WITH REAR SPOILER TYPE
  HIGH-MOUNTED STOPLIGHT

TAILLIGHT, POSITION LIGHT, FRONT SIDE MARKER LIGHT AND LICENSE PLATE LIGHT

TSB Revision

CIRCUIT DIAGRAMS

90-93

RELAY BOX

(FUSE     )

JOINT
CONNECTOR (1)

JUNCTION
BLOCK

REAR
COMBINATION
LIGHT (RH)

FRONT
COMBINATION
LIGHT (RH)

20

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE
BR :BROWN     O : ORANGE     GR : GRAY     R : RED     W : WHITE
SB : SKY BLUE     P : PINK      Y : YELLOW     V : VIOLET

FRONT SIDE
MARKER
LIGHT

(LH)

(RH)

TAILLIGHT, POSITION LIGHT, FRONT SIDE MARKER LIGHT AND LICENSE PLATE LIGHT

TSB Revision

CIRCUIT DIAGRAMS

90-94

TAILLIGHT, POSITION LIGHT, FRONT SIDE MARKER LIGHT AND LICENSE PLATE LIGHT (CONTIN-
UED)

FRONT-ECU

RELAY BOX
(FUSE     )

JOINT
CONNECTOR (1)

COLUMN-ECU

JOINT
CONNECTOR (2)

IGNITION
SWITCH (IG1)

JUNCTION
BLOCK

COLUMN
SWITCH

22

LIGHTING SWITCH

NOTE

·AUDIO SYSTEM
·AUTO-CRUISE
 CONTROL SYSTEM
·AUTOMATIC AIR
 CONDITIONING
 SYSTEM
·BRAKE WARNING
 LIGHT, OIL PRESSURE
 WARNING LIGHT,
 FUEL WARNING LIGHT
·CENTRAL DOOR
 LOCKING SYSTEM
·CHARGING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·DOOR AJAR WARNING
 TONE ALARM
·ELECTRONIC BRAKE-
 FORCE DISTRIBUTION
 (EBD) AND ANTI-LOCK
 BRAKING SYSTEM (ABS)
·ENGINE IMMOBILIZER
 SYSTEM
·FRONT DOME LIGHT,
 REAR DOME LIGHT,
 TRUNK LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·INVECS-II 4A/T
·MANUAL AIR
 CONDITIONING SYSTEM
·METER AND GAUGE
·MFI SYSTEM
·MULTI CENTER DISPLAY
·SEAT BELT WARNING
 TONE ALARM
·SUPPLEMENTAL
 RESTRAINT SYSTEM (SRS)
·VANITY MIRROR LIGHT

:

JUNCTION BLOCK SIDE

UPPER
SIDE
