Mitsubishi Galant (2004+). Manual - part 79

INVECS-II 4A/T <3.8L ENGINE>

TSB Revision

CIRCUIT DIAGRAMS

90-75

POWERTRAIN
CONTROL
MODULE

A/T CONTROL
SOLENOID
VALVE ASSEMBLY

NOTE

UNDERDRIVE
SOLENOID
VALVE
SECOND
SOLENOID
VALVE
OVERDRIVE
SOLENOID
VALVE
TORQUE
CONVERTER
CLUTCH
CONTROL
SOLENOID
VALVE
LOW AND
REVERSE
SOLENOID
VALVE

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW
SB : SKY BLUE     BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET

TRANSMISSION
FLUID
TEMPERATURE
SENSOR

INVECS-II 4A/T <3.8L ENGINE>

TSB Revision

CIRCUIT DIAGRAMS

90-76

INVECS-II 4A/T <3.8L ENGINE> (CONTINUED)

MFI SYSTEM

MULTI CENTER
DISPLAY <LOW>

ACCELERATOR
PEDAL
POSITION
SENSOR

(MAIN)

(SUB)

HALL IC

HALL IC

INVECS-II 4A/T <3.8L ENGINE>

TSB Revision

CIRCUIT DIAGRAMS

90-77

DATA LINK
CONNECTOR

POWERTRAIN
CONTROL
MODULE

JUNCTION
BLOCK

FUSIBLE
LINK

1

AUTO-CRUISE
CONTROL SYSTEM

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE
BR :BROWN     O : ORANGE     GR : GRAY     R : RED     W : WHITE
SB : SKY BLUE     P : PINK      Y : YELLOW     V : VIOLET

HEADLIGHT <2-BULB TYPE>

TSB Revision

CIRCUIT DIAGRAMS

90-78

HEADLIGHT <2-BULB TYPE>

M1901001500750

BATTERY

FRONT-
ECU

PULSE WIDTH
MODULATOR

RELAY
BOX

HEADLIGHT
RELAY: HIGH

HEADLIGHT
 (LH)

HEADLIGHT
 (RH)

FIELD EFFECT
TRANSISTOR FOR
HEADLIGHT: LOW
