The exhaust pipe is diveided into five <3.0L Engine>
or four <2.4L Engine> parts.
IN TA K E A N D EXH A U ST D IA G N O SIS
INTRODUCTION
M1151006900075
The occurrence of exhaust leakage or abnormal
noise is caused by cracks or strain in the gasket, or
by when the exhaust pipe or muffler is damaged due
to impacts during travel. The exhaust leaks from
these sections and causes the exhaust noise to
increase. There may be cases when there is
interference with the body and vibration noise is
generated.
TROUBLESHOOTING STRATEGY
M1151007000075
Use these steps to plan your diagnostic strategy. If
you follow them carefully, you will be sure that you
have exhausted most of the possible ways to find an
intake or exhaust fault.
1. Gather information from the customer.
2. Verify that the condition described by the
customer exists.
3. Find the malfunction by following the SYMPTOM
CHART.
4. Verify malfunction is eliminated.
SYMPTOM CHART
M1151007100072
SYMPTOM PROCEDURES
Inspection Procedure 1
M1151007300032
Exhaust leakage
DIAGNOSIS
STEP 1. Check the gasket for cracks damage.
Q: Is the gasket damaged?
YES :
Replace the gasket, then go Step 3.
NO :
Go to Step 2.
STEP 2. Check for loosening in each coupling
section.
Q: Is there any loosening in each section?
YES :
Tighten, then go to Step 3.
NO :
There is no action to be taken.
STEP 3. Check symptom.
Q: Is the exhaust leaking?
YES :
Return to Step 1.
NO :
This diagnosis is complete.
SYMPTOMS
INSPECTION PROCEDURE
REFERENCE PAGE
Exhaust leakage
1
Abnormal noise generation
2
