MAINTENANCE SERVICE

TSB Revision

GENERAL <BODY AND CHASSIS>

00-41

<When using the tension gauge>
Use a belt tension gauge to check that the belt tension is within
the standard value.

Standard value:

ITEM

2.4L ENGINE

3.0L ENGINE

Tension N (lb) 392

−

588 (88

−

132)

490

−

686 (110

−

154)

AKX01151

AKX01151AB

TENSION GAUGE

WATER PUMP
PULLEY

CRANK-
SHAFT
PULLEY

GENERATOR
PULLEY

<2.4L ENGINE>

AKX01152

AKX01152 AB

IDLER
PULLEY

A/C COM-
PRESSOR
PULLEY

GENERATOR
PULLEY

CRANK
SHAFT
PULLEY

TENSION
GAUGE

TENSIONER
PULLEY

<3.0L ENGINE>

MAINTENANCE SERVICE

TSB Revision

GENERAL <BODY AND CHASSIS>

00-42

<Belt deflection check>
Apply 98 N (22 pounds) of force to the middle of the drive belt
between the pulleys (at the place indicated by the arrow) and
check that the amount of deflection in within the standard
value.

Standard value:

Generator Drive Belt Tension Adjustment <2.4L
ENGINE>

1. Loosen the nut of the generator pivot bolt.

2. Loosen the lock bolt.

3. Turn the adjusting bolt to adjust the belt vibration frequency,

belt tension or deflection to the standard value.

Standard value:

ITEM

2.4L ENGINE 3.0L ENGINE

Deflection (Reference value)
mm (in)

6.7

−

9.0

(0.26

−

0.35)

8.5

−

10.9

(0.33

−

0.43)

AKX01153

AKX01153 AB

<2.4L ENGINE>

WATER PUMP
PULLEY

GENERATOR
PULLEY

CRANK-
SHAFT
PULLEY

98 N (22 lb)

AKX01154

AKX01154 AB

<3.0L ENGINE>

IDLER
PULLEY

A/C COM-
PRESSOR
PULLEY

GENERATOR
PULLEY

TENSIONER
PULLEY

CRANK
SHAFT
PULLEY

98 N (22 lb)

ITEMS

DURING
ADJUSTMENT

DURING
REPLACEMENT

Vibration frequency Hz

201

−

222

267

−

299

Tension N (lb)

441

−

539

(99

−

121)

785

−

981

(176

−

220)

Deflection (Reference value)
mm (in)

7.2

−

8.4

(0.28

−

0.33)

4.4

−

5.3

(0.17

−

0.21)

AKX01155

AKX01155 AB

ADJUSTING
BOLT

LOCK BOLT

PIVOT BOLT

<2.4L ENGINE>

MAINTENANCE SERVICE

TSB Revision

GENERAL <BODY AND CHASSIS>

00-43

4. Tighten the lock bolt.

Tightening torque: 23 N

⋅⋅⋅⋅

m (16 ft-lb)

5. Tighten the nut of the generator pivot bolt.

Tightening torque: 44 N

⋅⋅⋅⋅

m (33 ft-lb)

6. Tighten the adjusting bolt.

Tightening torque: 4.9 N

⋅⋅⋅⋅

m (44 in-lb)

Generator and A/C Compressor Drive Belt
Tension Adjustment <3.0L ENGINE>

1. Loosen the tensioner pulley fixing nut.

2. With the tensioner pulley fixing nut temporarily tightened to

15 N

⋅

m (11 ft-lb), set the belt tension or defection amount to

the standard value using the adjusting bolt.

Standard value:

3. Tighten the tension pulley fixing nut.

Tightening torque: 49 N

⋅⋅⋅⋅

m (36 ft-lb)

ITEMS

DURING
ADJUSTMENT

DURING
REPLACEMENT

Vibration frequency Hz

141

−

153

170

−

190

Tension N (lb)

539

−

637

(121

−

143)

785

−

981

(176

−

221)

Deflection (Reference value)
mm (in)

9.0

−

10.1

(0.35

−

0.40)

6.2

−

7.6

(0.24

−

0.30)

AKX01156

TENSIONER
PULLEY

FIXING
NUT

ADJUSTING BOLT

MAINTENANCE SERVICE

TSB Revision

GENERAL <BODY AND CHASSIS>

00-44

Power Steering Oil Pump and A/C Compressor
<2.4L ENGINE> Drive Belt Tension Check and
Adjustment

Check the drive belt tension by the following procedure.
<When using scan tool MB991502>

Required Special Tools:

•

MB991502: Scan Tool (MUT-II)

•

MB991668: Belt Tension Meter Set

Gently tap the middle of the belt between the pulleys (the
location indicated by the arrow) with your finger as shown in the
illustration, and check that the vibration frequency of the belt is
within the standard value range.

NOTE: Refer to

P.00-40

for details on the method of measuring

the vibration frequency using the scan tool.

<When using a tension gauge>
Use a belt tension gauge to check that the belt tension is within
the standard value.

Standard value:

<2.4L ENGINE>

<3.0L ENGINE>

ITEMS

WHEN
CHECKED

DURING
ADJUSTMENT

DURING
REPLACEMENT

Vibration
frequency
Hz

108

−

132

114

−

126

137

−

157

Tension N
(lb)

392

−

588

(88

−

132)

441

−

539

(99

−

121)

637

−

834

(143

−

187)

Deflection
(Reference
value) mm
(in)

11.7

−

15.3

(0.46

−

0.60)

12.5

−

14.3

(0.49

−

0.56)

8.8

−

11.0

(0.35

−

0.43)

ITEMS

WHEN
CHECKED

DURING
ADJUSTMENT

DURING
REPLACEMENT

Vibration
frequency
Hz

125

−

154

133

−

148160

−

183

Tension N
(lb)

373

−

569

(84

−

128)

422

−

520

(95

−

117)

608

−

804

(137

−

181)

Deflection
(Reference
value) mm
(in)

11.0

−

14.3

(0.43

−

0.56)

11.7

−

13.3

(0.46

−

0.53)

8.4

−

10.4

(0.33

−

0.41)

AC000087

<2.4L ENGINE>

(VEHICLES WITHOUT A/C)

(VEHICLES WITH A/C)

OIL PUMP PULLEY

CRANKSHAFT
PULLEY

A/C
COMPRESSOR
PULLEY

AC000088

<3.0L ENGINE>

POWER STEERING
OIL PUMP PULLEY

CRANKSHAFT PULLEY
