AUTOMATIC TRANSAXLE DIAGNOSIS TSB Revision AUTOMATIC TRANSAXLE 23A-78 (4) Measure the voltage between PCM terminal 111 and ground. • The voltage should measure between 4.5 and 4.9 volts. (5) Turn the ignition switch to the "LOCK" (OFF) position. YES : Go to Step 7. STEP 7. Check PCM connector B-22 and input shaft speed YES : Go to Step 8. GROUP 00E, Harness Connector Inspection AC210374 JAE 94 98 107 103 112 91 100 109 101 102 106 110 105 111 97 92 96 93 104 113 108 95 99 B-22 HARNESS AC AC306248AE B-22 CONNECTOR: B-22 PCM AIR JAE 94 98 107 103 112 91 100 109 101102 106 110 105 111 97 92 96 93 104 113 108 95 99 AC305354 TRANSMISSION B-109 (GR) AC CONNECTOR: B-109 1 3 2 |
