HOOD TSB Revision BODY 42-4 HOOD BODY DIAGNOSIS INTRODUCTION TO HOOD DIAGNOSIS M1421005800363 Wind noise at the hood may be caused by improper HOOD DIAGNOSTIC TROUBLESHOOTING STRATEGY M1421005900337 Use these steps to plan your diagnostic strategy. If 2. Verify that the condition described by the customer exists. 3. Find the malfunction by following the Symptom Chart. 4. Verify malfunction is eliminated. SYMPTOM CHART M1421006000371 SYMPTOM PROCEDURES INSPECTION PROCEDURE 1: Difficult Locking and Unlocking DIAGNOSIS STEP 1. Check that the release cable is routed Q: Is the release cable routed correctly? YES : Go to Step 2. NO : Re-route the release cable. Then go to Step STEP 2. Check the engagement of the hood latch Q: Are the hood latch and hood striker engaged correctly? Go to Step 3. NO : Adjust the hood latch (Refer to Then go to Step 4. STEP 3. Check for proper lubrication of release Q: Is the release cable properly lubricated? YES : Go to Step 4. NO : Lubricate, then go to Step 4. STEP 4. Retest the system. Q: Does the hood lock operate easily? YES : The procedure is complete. NO : Return to Step 1. SYMPTOM INSPECTION REFERENCE PAGE Difficult locking and unlocking 1 Uneven body clearance 2 Uneven height 3 |
