DOOR MIRROR TSB Revision EXTERIOR 51-34 STEP 4. Check the ground circuit to between remote and check at the wiring harness side connector. (2) Measure the resistance value between terminal 3 and ground. • The resistance should equal 2 ohms or less. Q: Is the measured resistance 2 ohms or less? YES : Go to Step 6. STEP 5. Check the wiring harness between remote AC307125 E-09 (GR) CONNECTOR: E-09 HARNESS SIDE AC AC307127 CONNECTOR: E-09 AB AC307125 E-09 (GR) CONNECTOR: E-09 HARNESS SIDE AC |
