ON-VEHICLE SERVICE TSB Revision HEATER, AIR CONDITIONING AND VENTILATION 55A-260 4. At this time, check to see that the voltage of A/C pressure sensor terminal No. 2 reflects the specifications of the fig- ± 5%. COMPRESSOR DRIVE BELT ADJUSTMENT M1552001000357 Refer to GROUP 00, Maintenance Service − Drive Belts CHARGING M1552001200403 Use the refrigerant recovery station to charge the refrigerant. METHOD BY USING REFRIGERANT RECOVERY Using the refrigerant recovery and recycling unit, refill the DISCHARGING SYSTEM Use the refrigerant recovery unit to discharge refrigerant gas REFILLING OF OIL IN THE A/C SYSTEM Too little oil will provide inadequate compressor lubrication and 3 (4.7 fl.oz) of refrigerant oil. While the A/C system is in operation, the oil is carried through the entire system by the Compressor oil: SUN PAG 56 Evaporator: 60 cm 3 (2.0 fl.oz) Condenser: 15 cm 3 (0.5 fl.oz) Suction hose: 10 cm 3 (0.3 fl.oz) AC208297AB REFRIGERANT PRESSURE (MPa) OUTPUT VOLTAGE (V) 0 1 2 3 5 4 1 2 3 |
