MANUAL A/C DIAGNOSIS TSB Revision HEATER, AIR CONDITIONING AND VENTILATION 55A-48 DTC U1100: Powertrain Control Module Time-out (Related to Engine) CAUTION If DTC U1100 is set in the A/C-ECU, diagnose the CAUTION Whenever the ECU is replaced, ensure that the . TROUBLE JUDGMENT The A/C-ECU receives engine control sys- . TECHNICAL DESCRIPTION (COMMENT) Current trouble • Connector(s) or wiring harness in the CAN bus lines between the powertrain control module and Past trouble • If DTC U1100 is stored as a past trouble, carry out diagnosis with particular emphasis on wiring − How to Cope with Intermit- ) and check the CAN bus lines. You can narrow down the possible . TROUBLESHOOTING HINTS • Powertrain control module failed • Malfunction of the A/C-ECU • Damaged harness wires and connectors DIAGNOSIS Required Special Tools: • MB991958: Scan Tool (MUT-III Sub Assembly) • MB991824: Vehicle Communication Interface (V.C.I.) • MB991827: MUT-III USB Cable • MB991910: MUT-III Main Harness A (Vehicles with CAN communication system) |
