METER AND GAUGE

TSB Revision

CIRCUIT DIAGRAMS

90-126

METER AND GAUGE (CONTINUED)

LCD
ODO/TRIP

ODO/TRIP
SWITCH

RHEOSTAT
CIRCUIT

RHEOSTAT

(FUSE     )

20

JUNCTION
BLOCK

(FUSE     )

23

JOINT
CONNECTOR (2)

(FUSE     )

22

JOINT
CONNECTOR (1)

METER AND GAUGE

TSB Revision

CIRCUIT DIAGRAMS

90-127

COMBINATION METER

MAIN
CLOCK

SUB
CLOCK

SPEED
METER

FUEL
GAUGE

TEMP
GAUGE

TACHO
METER

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW
SB : SKY BLUE     BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET

METER AND GAUGE

TSB Revision

CIRCUIT DIAGRAMS

90-128

METER AND GAUGE (CONTINUED)

IGNITION
SWITCH (IG1)

JUNCTION
BLOCK

JOINT
CONNECTOR (2)

JOINT
CONNECTOR (1)

OUTPUT SHAFT
SPEED SENSOR

POWERTRAIN
CONTROL
MODULE

IGNITION
SYSTEM

<3.8L ENGINE>

NOTE

: WITHOUT ELECTRONIC BRAKE-FORCE DISTRIBUTION (EBD)
  AND ANTI-LOCK BRAKING SYSTEM (ABS)
: WITH ELECTRONIC BRAKE-FORCE DISTRIBUTION (EBD)
  AND ANTI-LOCK BRAKING SYSTEM (ABS)

: 2.4L ENGINE
: 3.8L ENGINE

INVECS-II
4A/T

METER AND GAUGE

TSB Revision

CIRCUIT DIAGRAMS

90-129

JOINT
CONNECTOR (3)

COMBINATION
METER

DATA LINK
CONNECTOR

MULTI-CENTER DISPLAY UNIT

ABS-ECU OR
ABS/TCL-ECU

WIRE COLOR CODE
B : BLACK     SB : SKY BLUE
BR : BROWN     LG : LIGHT GREEN
G : GREEN P : PINK     GR : GRAY
R : RED     L : BLUE     Y : YELLOW
V : VIOLET     W : WHITE     O : ORANGE
