AIR BAG MODULE AND SEAT BELT PRE-TENSIONER DISPOSAL PROCEDURES TSB Revision SUPPLEMENTAL RESTRAINT SYSTEM (SRS) 52B-398 CAUTION Once disconnected, both electrodes of the front passen- 3. Prepare two wires longer than 6 meters (20 feet) for deployment and connect the terminals in one end to CAUTION Never fail to do Step 4 in order to prevent accidental static electricity. 5. Using pliers, cut the passenger’s air bag module connector from the harnesses. Connect the deployment wires to each 6. Pass the thick wire through the air bag module mounting hole, and then secure the air bag module to an old tire with a 7. Place three old tires without wheels on top of the tire secured to the air bag module, and secure all tires together AC100450AB DEPLOYMENT WIRES SHORTED 6m (20 ft) OR LONGER AC307163AB FRONT PASSENGER'S INSULATION DEPLOYMENT WIRES CONNECTION AC100483 DEPLOYMENT WIRES FRONT PASSENGER'S AIR BAG MODULE AB ACX00611 TIRES WITHOUT DEPLOYMENT AB |
