SRS AIR BAG DIAGNOSIS TSB Revision SUPPLEMENTAL RESTRAINT SYSTEM (SRS) 52B-174 STEP 5. Check the harness wires for short circuit to C-122 (terminal No.9 and 10) and side-airbag module connector C-122 and side-airbag module (LH) STEP 6. Recheck for diagnostic trouble code. Q: Is DTC B1433 set? YES : Return to Step 1. AC305362 CONNECTOR: C-122 C-122 (Y) AI SRS-ECU C-122 A B 18 10 15 7 13 5 14 6 16 8 17 9 19 11 20 12 1 2 3 4 AC307778 CONNECTOR : D-24 AC D-24 (R) 2 1 HARNESS SIDE AC305412 AB MB991910 DATA LINK CONNECTOR MB991824 MB991827 |
