DIAGNOSIS TSB Revision CONTROLLER AREA NETWORK (CAN) 54C-76 (3) Measure the voltage between data link connector terminal 6 and body ground. OK: 4.0 V or less Q: Does the voltage measure 4.0 V or less? YES : If the voltage measures 4.0 V or less, go to Step 3. AC209365 HARNESS SIDE: C-125 TEST FN Y 8 16 15 7 5 1314 6 12 4 2 1011 3 9 1 |
