MULTIPORT FUEL INJECTION (MFI) DIAGNOSIS TSB Revision MULTIPORT FUEL INJECTION (MFI) <3.8L ENGINE> 13B-764 STEP 5. Measure the sensor output voltage at PCM (2) Connect special tool MB991923 (check harness) between the PCM and the body-side harness connector. (3) Turn the ignition switch to the "ON" position. AC306248 B-20 HARNESS CONNECTOR: COMPONENT SIDE AB B-20 CONNECTOR: B-20 PCM AIR AC209793AJ SPECIAL TOOL 23-PIN CONNECTOR B-20 PCM MB991923 BODY SIDE |
