Mitsubishi Space Star. Manual - part 135





ABS <2WD> –

Troubleshooting

35B-5

INSPECTION PROCEDURE FOR TROUBLE SYMPTOMS

Inspection Procedure 2

Communication with MUT-

II

 is not possible.

(Communication with ABS only is not possible.)

Probable cause

When communication with the MUT-

II

 is not possible, the cause is probably an

open circuit in the ABS-ECU power circuit or an open circuit in the diagnosis output
circuit.



Blown fuse



Malfunction of wiring harness or connector



Malfunction of ABS-ECU

Measure at diagnosis connector B-35
and ABS-ECU connector A-47.



Disconnect the connector and
measure at the harness side.



Continuity between the following
terminals
OK: Continuity
ABS-ECU side

11

12

|

|

Diagnosis connector side

7

1

NG

Check the following connectors:
A-47, B-35, B-42, B-60X, B-61X

NG

Repair

OK

Check trouble symptoms.

NG

Check the harness between the ABS-
ECU and diagnosis connector, and re-
pair if necessary.

OK

Measure at ABS-ECU connector A-47.



Disconnect the connector and
measure at the harness side.



Ignition switch: ON



Voltage between 15 – Body earth
OK: System voltage

NG

Check the following connectors:
A-47, B-42, B-80, B-77

NG

Repair

OK

Check trouble symptoms.

NG

Check the harness between fuse No.
5 inside the junction block and ABS-
ECU, and repair if necessary.

OK

Measure at ABS-ECU connector A-47.



Disconnect the connector and
measure at the harness side.



Continuity between
16, 19 – Body earth
OK: Continuity

NG

Repair

OK

Check the following connector:
A-47

NG

Repair

OK

Check trouble symptoms.

NG

Replace the hydraulic unit assembly.

ABS <2WD> –

Troubleshooting

35B-6

Inspection Procedure 5

Brake operation is abnormal.

Probable cause

This varies depending on the driving conditions and the road surface conditions,
so problem diagnosis is difficult. However, if a normal diagnosis code is displayed,
carry out the following inspection.



Improper installation of wheel speed sensor



Incorrect sensor harness contact



Foreign material adhering to wheel speed sensor



Malfunction of wheel speed sensor



Malfunction of ABS rotor



Malfunction of wheel bearing



Malfunction of hydraulic unit



Malfunction of ABS-ECU

Wheel speed sensor installation in-
spection

NG

Repair

OK

Wheel speed sensor output voltage
inspection (Refer to P.35B-8)

NG

Wheel speed sensor inspection

NG

Replace the wheel speed sensor.

OK

ABS rotor inspection

NG

Replace the ABS rotor.

OK

Wheel bearing inspection.

NG

Repair

OK

Check the following connectors:
A-22, A-02, B-42, D-15, D-14, D-12

NG

Repair

OK

Check trouble symptom.

NG

Measure at ABS-ECU connector A-47.



Disconnect the connector and
measure at the harness side.



Resistance value between terminals
1  – 2, 4 – 5, 6 – 7 and 8 – 9.
OK: 1.28  – 1.92 k

(The sensor harness and connector
should be moved while these
inspections are carried out.)

NG

Repair

OK

Check the following connector:
A-47

NG

Repair

OK

Check trouble symptom.

NG

Replace the hydraulic unit assembly.

OK

Hydraulic unit check

ABS <2WD> –

Troubleshooting

35B-7

CHECK AT ABS-ECU

TERMINAL VOLTAGE CHECK CHART

1.

Measure the voltages between terminals (16) and (19) (earth terminals) and each respective terminal.

2.

The terminal layouts are shown in the illustrations below.

Connector
terminal
No.

Signal

Checking requirements

Normal condition

11

MUT-

II

Connect the MUT-

II

.

Serial communication with
MUT-

II

Do not connect the MUT-

II

.

1 V or less

12

Input from diagnosis indica-
tion selection

Connect the MUT-

II

.

0 V

tion selection

Do not connect the MUT-

II

.

Approx. 12 V

14

Input from stop lamp switch

Ignition switch:
ON

Stop lamp switch: ON

System voltage

ON

Stop lamp switch: OFF

1 V or less

15

ABS-ECU power supply

Ignition switch: ON

System voltage

Ignition switch: START

0 V

17

Pump motor power supply

Always

System voltage

18

Solenoid valve power supply

Always

System voltage

20

Output to ABS warning lamp

Ignition switch:
ON

The lamp is switched off.

System voltage

ON

The lamp is illuminated.

0 – 2 V

ABS <2WD> –

Troubleshooting/On-vehicle Service

35B-8

RESISTANCE AND CONTINUITY BETWEEN HARNESS-SIDE CONNECTOR TERMINALS

1.

Turn the ignition switch off and disconnect the ABS-ECU connectors before checking resistance and
continuity.

2.

Check them between the terminals indicated in the table below.

3.

The terminal layouts are shown in the illustrations below.

Connector terminal No.

Signal

Normal condition

1 – 2

Rear-right wheel speed sensor (+ wire)

1.28 – 1.92 k

4 – 5

Front-right wheel speed sensor (+ wire)

1.28 – 1.92 k

6 – 7

Front-left wheel speed sensor (+ wire)

1.28 – 1.92 k

8 – 9

Rear-left wheel speed sensor (+ wire)

1.28 – 1.92 k

16 – Body earth

ABS-ECU earth

Continuity

19 – Body earth

ON-VEHICLE SERVICE

WHEEL SPEED SENSOR OUTPUT VOLTAGE
CHECK

Measurement terminal No. has been changed. The same
procedures as before are applied except for the items shown
below.

Wheel
speed
sensor

Front left

Front right

Rear left

Rear right

Terminal
No

6

4

8

1

No.

7

5

9

2
