AUTOMATIC TRANSMISSION –

Transmission Control

23-63

INSPECTION

WIDE OPEN THROTTLE SWITCH CHECK

Switch position

Terminal No.

1

2

ON

OFF

OFF

ON

AUTOMATIC TRANSMISSION –

Transmission Control

AUTOMATIC TRANSMISSION –

Transmission Control

23-64

SELECTOR LEVER ASSEMBLY
DISASSEMBLY AND REASSEMBLY

11

1

2

3

4

16

8

9

10

13

12

7

6

9

5

14

14

15

17

18

19

20

20

21

23

24

23

27

28

33

30

32

31

26

29

22

25

5.0

Nm

12

  Nm

12

  Nm

12

  Nm

12

  Nm

1.5

  Nm

12

  Nm

Disassembly steps

1. Push button
2. Spring
3. Adjuster
4. Shift knob
5. Indicator panel assembly
6. Shift switch assembly
7. Position indicator lamp assembly
8. Return spring
9. Bushing

10. Pipe

11. Bracket

12. Lever assembly
13. Lever
14. Shift bushing
15. Pipe
16. Select lever
17. Roller

18. Spring
19. Manual lever
20. Shift bushing
21. Pipe
22. Cable lever
23. Shift bushing
24. Pipe
25. Detent spring assembly
26. Lock cam
27. Guide block
28. Rubber stopper
29. Cushion
30. Steel ball
31. Ball support
32. Spring
33. Bracket assembly

AUTOMATIC TRANSMISSION –

Transmission Control

23-65

INSPECTION

SHIFT SWITCH ASSEMBLY CONTINUITY CHECK

Switch position

Terminal No.

1

2

3

4

5

6

Select switch

ON

OFF

Shift switch
(UP)

ON

(UP)

OFF

Shift switch
(DOWN)

ON

(DOWN)

OFF

Shift switch
(DOWN)

ON

ON

OFF

ON

OFF

Shift switch
(UP)

Select
switch

AUTOMATIC TRANSMISSION –

Shift Lock and Key Interlock Mechanisms

23-66

SHIFT LOCK AND KEY INTERLOCK MECHANISMS

REMOVAL AND INSTALLATION

NOTE
When removing and installing the transmission control cable and shift lock cable unit, be careful not to
hit them against the SRS-ECU.

12 Nm

1

2

3

4

5

6

7

12 Nm

Key interlock cable removal steps



Front floor console



B



1. Key interlock cable connection

(Selector lever side)



Lower column cover

2. Cover



A



3. Key interlock cable connection

(Steering lock cylinder side)

4. Key interlock cable

Shift lock cable removal steps



Front floor console



A



5. Shift lock cable connection

(Selector lever side)



Under cover

6. Shift lock cable connection

(Brake pedal side)

7. Shift lock cable
