Mitsubishi Lancer. Manual - part 194





AC304921AC

57 ± 7 N·m

15 ± 3 N·m

70 ± 10 N·m

3

5

2

4

1

<RH drive vehicles>

6

7

Removal steps

1. Crossmember (Refer to GROUP 32,

Crossmember

P.32-8

).

>>

A

<< 2. Joint cover grommet

3. Return hose connection
4. Return tube
5. Pressure hose connection
6. Clamp
7. Steering gear and linkage

POWER STEERING GEAR BOX AND LINKAGE

POWER STEERING

37-24

INSTALLATION SERVICE POINT
>>A<< JOINT COVER GROMMET INSTAL-
LATION

AC304922 AB

A

B

Joint cover
grommet

Steering gear

Align the joint cover grommet notch (arrow A) with
the steering gear lug (arrow B), and then install the
steering joint cover to the steering gear.

INSPECTION

M1372011000538

STEERING GEAR TOTAL PINION
TORQUE CHECK

CAUTION

When holding the steering gear in a vice, secure
its mounting positions. If it is secured in any
other place, the gear housing may become
deformed or damaged.

AC000996 AC

MB991006

Using special tool preload socket (MB991006), rotate
the pinion gear at the rate of one rotation in approxi-
mately 4 to 6 seconds to check the total pinion
torque.

Standard value:

0.8

 2.1 <Invite>

0.7

 2.1 <Intense>

[Change in torque: 0.6 N

⋅ m or less]

POWER STEERING GEAR BOX AND LINKAGE

POWER STEERING

37-25

NOTE: When measuring, remove the bellows from
the rack housing. Measure the pinion torque through
the whole stroke of the rack.
If the measured value is not within the standard
range, first adjust the rack support cover, and then
check the total pinion torque again.
If the total pinion torque cannot be adjusted to within
the standard range by adjusting the rack support
cover, check the rack support cover, rack support
spring, rack support and replace any parts if neces-
sary.

TIE ROD SWING RESISTANCE CHECK

1. Give 10 hard swings to the tie rod.

AC000997

2. Measure the tie rod swing resistance [tie rod

swing torque] with a spring balance.

Standard value: 8

 27 N [1.5  4.9 N⋅ m]

3. If the measured value exceeds the standard

value, replace the tie rod.

4. If the measured value is below the standard value,

the tie rod can be re-used if it swings smoothly
without excessive play.

TIE ROD END BALL JOINT DUST COVER
CHECK

1. Check the dust cover for cracks or damage by

pushing it with your finger.

2. If the dust cover is cracked or damaged, replace

the tie rod end (Refer to

P.37-26

).

NOTE: Cracks or damage of the dust cover may
damage the ball joint. If it is damaged during serv-
ice work, replace the dust cover (Refer to

P.37-35

).

POWER STEERING GEAR BOX AND LINKAGE

POWER STEERING

37-26

DISASSEMBLY AND REASSEMBLY

M1372011100193

<LH drive vehicles>

AC100244AC

3

13 ± 3 N·m

Steering gear seal kit

Flare nut

Repair kit grease

23

21

19

4

11 8

28

29

32

31

17

35

11

8

22 ± 4 N·m

59 ± 10 N·m

23 ± 2 N·m
        -30˚

12

14

15

33

17

59 ± 10 N·m

25 ± 4 N·m

18

24

23

20

19

21

22

13

34

4

4

3

1

36

2

16

30

31

32

27

29

28

25

26

11

88 ± 10 N·m

10

8

9

7

5

6

52 ± 2 N·m

35

Disassembly steps

>>

O

<< 1.

Gear mounting rubber

2.

Gear housing mounting bushing

3.

Feed pipe

4.

O-ring

>>

N

<< 5.

Lock nut

>>

N

<< 6.

Tie rod end

7.

Clip

>>

M

<< 8.

Bellows band

9.

Bellows

>>

L

<< 10.

Tie rod

>>

L

<< 11.

Tab washer

>>

K

<< •

Total pinion torque adjustment

>>

J

<< 12.

Lock nut

<<

A

>> >>

J

<< 13.

Rack support cover

14.

Support spring

15.

Rack support

>>

I

<< 16.

End plug

17.

Lock nut

18.

Valve housing assembly

<<

B

>> >>

H

<< 19.

Lower oil seal

<<

B

>>

20.

Pinion and valve assembly

<<

C

>> >>

G

<< 21.

Seal ring

<<

D

>> >>

F

<< 22.

Upper bearing

<<

D

>> >>

F

<< 23.

Upper oil seal

24.

Valve housing

<<

E

>> >>

E

<< 25.

Circlip

<<

F

>>

26.

Rack stopper

<<

F

>> >>

D

<< 27.

Rack bushing

<<

F

>> >>

D

<< 28.

Oil seal

<<

F

>>

29.

O-ring

<<

F

>> >>

C

<< 30.

Rack assembly

<<

C

>>

31.

Seal ring

32.

O-ring

<<

G

>> >>

B

<< 33.

Lower bearing

<<

H

>> >>

B

<< 34.

Needle bearing

<<

I

>> >>

A

<< 35.

Oil seal

36.

Gear housing

Disassembly steps (Continued)

POWER STEERING GEAR BOX AND LINKAGE

POWER STEERING

37-27

<RH drive vehicles>

AC102865

3

23

21

19

4

11 8

8

11 35

17 31

32

29 28

6

5

7

9

8

10

11

25

26

28

29

27

32

31

30

12

13

14

15

16

17

33

35

36

1

4

2

34

4

4

3

24

23

22

21

20

19

18

AD

Steering gear seal kit

Flare nut

Repair kit grease

22 ± 4 N·m

59 ± 10 N·m

25 ± 4 N·m

88 ± 10 N·m

52 ± 2 N·m

59 ± 10 N·m

13 ± 3 N·m

23 ± 2 N·m        -30˚

Disassembly steps

>>

O

<< 1.

Gear mounting rubber

2.

Gear housing mounting bushing

3.

Feed pipe

4.

O-ring

>>

N

<< 5.

Lock nut

>>

N

<< 6.

Tie rod end

7.

Clip

>>

M

<< 8.

Bellows band

9.

Bellows

>>

L

<< 10.

Tie rod

>>

L

<< 11.

Tab washer

>>

K

<< •

Total pinion torque adjustment

>>

J

<< 12.

Lock nut

<<

A

>> >>

J

<< 13.

Rack support cover

14.

Support spring

15.

Rack support

>>

I

<< 16.

End plug

17.

Lock nut

18.

Valve housing assembly

<<

B

>> >>

H

<< 19.

Lower oil seal

<<

B

>>

20.

Pinion and valve assembly

<<

C

>> >>

G

<< 21.

Seal ring

<<

D

>> >>

F

<< 22.

Upper bearing

<<

D

>> >>

F

<< 23.

Upper oil seal

24.

Valve housing

<<

E

>> >>

E

<< 25.

Circlip

<<

F

>>

26.

Rack stopper

<<

F

>> >>

D

<< 27.

Rack bushing

<<

F

>> >>

D

<< 28.

Oil seal

<<

F

>>

29.

O-ring

<<

F

>> >>

C

<< 30.

Rack assembly

<<

C

>>

31.

Seal ring

32.

O-ring

<<

G

>> >>

B

<< 33.

Lower bearing

<<

H

>> >>

B

<< 34.

Needle bearing

<<

I

>> >>

A

<< 35.

Oil seal

36.

Gear housing

Disassembly steps (Continued)
