Mitsubishi Lancer. Manual - part 174
SENSOR
COMPONENT LOCATIONS
70-6
SENSOR
M1701000600909
Name
Symbol
Name
Symbol
Air cleaner air flow sensor <4G6>
F
Output shaft speed sensor <A/T>
J
Air thermo sensor
M
Outside thermo sensor<Automatic
A/C>
H
Camshaft position sensor
D
Photo sensor <Automatic A/C>
L
Engine control detonation sensor
B
Side impact sensor (Front)
N
Engine control oxygen sensor (Front)
G
Side impact sensor (Rear)
O
Engine control oxygen sensor (Rear)
Q
Throttle body throttle sensor
C
Engine crank angle sensor
A
Vehicle speed sensor <M/T>
E
Heater water temperature sensor
<Automatic A/C>
M
Water temperature sensor unit
I
Inlet manifold absolute pressure sensor
(incorporating intake air temperature
sensor) <4G1>
C
Wheel speed sensor (Front)
P
Input shaft speed sensor <A/T>
J
Wheel speed sensor (Rear)
R
Inside air temperature sensor
<Automatic A/C>
K
AC501790
B
D
C
F
E
A
G
H
I
J
M
K
L
AB
AC501791
AB
N
O
P
O
R
*
*
*
*
NOTE: *: also equipped at the right side.
