REAR WIPER AND WASHER

CIRCUIT DIAGRAMS

90-286

REAR WIPER AND WASHER <LHD>  (CONTINUED)

INHIBITOR
SWITCH

BACK-UP
LAMP
SWITCH

A/T

M/T

(FUSE     )

3

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple

REAR WIPER AND WASHER

CIRCUIT DIAGRAMS

90-287

NOTES

REAR WIPER AND WASHER

CIRCUIT DIAGRAMS

90-288

REAR WIPER AND WASHER <RHD>

M1901006201650

IGNITION
SWITCH (IG1)

BATTERY

RELAY
BOX

·FRONT
 FOG LAMP

·TAIL LAMP,
 POSITION LAMP,
 LICENCE PLATE
 LAMP AND LIGHTING
 MONITOR BUZZER

·HEADLAMP

·WINDSHIELD
 WIPER AND
 WASHER

·REAR
 FOG LAMP

·HEADLAMP
 LEVELLING
 SYSTEM

POWER
SOURCE

COLUMN
SWITCH

FRONT
SIDE

J/B SIDE

NOTE

·CHARGING SYSTEM

·ABS
·BRAKE WARNING LAMP

·ENGINE CONTROL SYSTEM
·FUEL WARNING LAMP
·INVECS-II 4A/T
·METER AND GAUGE
·OIL PRESSURE WARNING LAMP

REAR
WIPER
SWITCH

REAR
WASHER
SWITCH

REAR WIPER AND WASHER

CIRCUIT DIAGRAMS

90-289

ETACS-ECU

IGNITION
SWITCH (ACC)

FUSIBLE
LINK

1

REAR WASHER
RELAY

REAR WIPER
RELAY

REAR
WIPER
MOTOR

DIAGNOSIS
CONNECTOR

REAR
WASHER
MOTOR

UPPER
SIDE

UPPER
SIDE
